Mitutoyo 103-151 Outside 350-375mm Micrometer
Condition:
Brand New
Brand New $523.00 /Each
$583.00 You save $60.00 10%
Notification
This product will be drop-shipped directly from the manufacturer. We will provide you with the manufacturer's lead time once advised.
Manufacturer warranty Description
Features:
- The frame has a hammertone baked enamel finish for durability
- Scale is laser etched on the thimble and sleeve
- Carbide facing on the spindle and anvil resists wear to keep surfaces flatter with longer accuracy
- Comes with standard bar except for 0-1" and 0-25mm models
- Supplied in a fitted plastic case
The Mitutoyo outside micrometer is ideal for measuring metal and non-metal workpieces. A ratchet-stop mechanism provides uniform pressure on a workpiece for precise, repeatable measurements. The friction thimble models allow for constant-force measurement for single-handed operation.
Technical details
Main features
- Scale Thimble and sleeve satin chrome finish, Dia. 18 mm
- Range 350-375mm
- Graduation 0,01 mm
- Measuring Force 5 - 10N
- Measuring Range (mm) 350 - 375
- Mass 2305g
- Flatness 1 µm
- Parallelism 5 µm
- Digital/Analog Analog
- Inch-Metric Metric
- Maximum Permissible Error J MPE ±6 µm
- Measuring spindle With spindle lock, Dia. 8 mm, spindle pitch 0,5 mm
