Buy Dahua PFM700-E, HDMI Extender 5 VDC Input Power

info@PrimeBuy.com

1-855-969-9322
1-908-282-3332 (Intl.)

Features:

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Transmission Signal	1 channel HDMI
Transmission Distance	50 m (max. 164 ft), with CAT6 pure copper cable (DC impedance < 9.5 ohm per 100 m / 328 ft)
Video Transmission Properties - Video Signal Input Interface	HDMI interface
Video Input Port	HDMI interface
Twisted-pair Video Transmission Port	RJ45 port
Input Voltage	DC5V
Power	TX <3W, RX <3W
HDCP Version Support	HDCP1.2
HDMI Version Support	1.3 and lower version
Resolution Output Signal	1080P/1080I/720P/576P/576I/480P/480I
Output Voltage	0.5~1.5 Vp-p
Impedance	Not specified
ESD	±6KV (contact discharge), ±8KV (air discharge), per IEC61000-4-2 1995 (GB/T 17626.5)
Anti-thunder	±2KV (common mode), ±1KV (differential mode), per IEC61000-4-5 1995 (GB/T 17626.5)
Stability	MTBF >5000 h
Physical Properties - Dimension (L x W x H)	Transmitter: 79.5 mm x 68 mm x 16.5 mm (3.13" x 2.68" x 0.65") Receiver: 79.5 mm x 68 mm x 16.5 mm (3.13" x 2.68" x 0.65")
Shell	Iron
Color	Black
N.W.	Transmitter: 133 g (0.29 lb) Receiver: 133 g (0.29 lb)
Environmental - Working Temperature	-10°C ~ 55°C (14°F ~ 131°F)
Storage Temperature	-20°C ~ 80°C (-4°F ~ 176°F)
Humidity	0~95% (non-condensing)
Certification	CE / FCC

Transmission Signal	1 channel HDMI
Transmission Distance	50 m (max. 164 ft), with CAT6 pure copper cable (DC impedance < 9.5 ohm per 100 m / 328 ft)
Video Transmission Properties - Video Signal Input Interface	HDMI interface
Video Input Port	HDMI interface
Twisted-pair Video Transmission Port	RJ45 port
Input Voltage	DC5V
Power	TX <3W, RX <3W
HDCP Version Support	HDCP1.2
HDMI Version Support	1.3 and lower version
Resolution Output Signal	1080P/1080I/720P/576P/576I/480P/480I
Output Voltage	0.5~1.5 Vp-p
Impedance	Not specified
ESD	±6KV (contact discharge), ±8KV (air discharge), per IEC61000-4-2 1995 (GB/T 17626.5)
Anti-thunder	±2KV (common mode), ±1KV (differential mode), per IEC61000-4-5 1995 (GB/T 17626.5)
Stability	MTBF >5000 h
Physical Properties - Dimension (L x W x H)	Transmitter: 79.5 mm x 68 mm x 16.5 mm (3.13" x 2.68" x 0.65") Receiver: 79.5 mm x 68 mm x 16.5 mm (3.13" x 2.68" x 0.65")
Shell	Iron
Color	Black
N.W.	Transmitter: 133 g (0.29 lb) Receiver: 133 g (0.29 lb)
Environmental - Working Temperature	-10°C ~ 55°C (14°F ~ 131°F)
Storage Temperature	-20°C ~ 80°C (-4°F ~ 176°F)
Humidity	0~95% (non-condensing)
Certification	CE / FCC

Note: Please read description carefully. Do not base your order on the picture presented.
