Schneider 21-1062672 Emerald 2.2 F-Mount Large Format Lens
Condition:
Brand New
Brand New $1,234.00 /Each
Notification
Item is non-returnable unless defective.
Please review our Return Policy.
Please review our Return Policy.
Manufacturer warranty Description
Schneider Optics, 21-1062672, Emerald 2.2/50mm F-Mount Large Format Lens
Features:
- F-Mount
- 43.2 mm image circle
- Optimized for short working distances
- 400-1000 nm broadband AR-coating
Applications:
- Machine Vision
- AOI (Automated Optical Inspection)
- Web inspection
- Factory automation
This compact and fast F-Mount lens is designed for large sensors up to 43.2 mm diagonal/length. It is optimized for a working distance range from 0.3 m to 2.0 m but can be used in many cases for longer working distances. The robust mechanics and a special focus setting and locking mechanism ensure the highest mechanical stability even in harsh environments.
Dimensions:
For more information, please see
Data Sheet
Technical details
Main features
- Interface F-Mount
- Focal Size (mm) 2.2/50
- Type F
- Mount Type F-Mount
- Storage Temperature [°C] -25 - +70
- Focal Length [mm] 50
- F/# Range F/2.2 - F/16
- Numerical Aperture [Object | Image] - | 0.21
- Maximum Sensor Size [mm] 43.2
- Maximum Angle of View [°] 45
- Recommendation Magnification Range -0. - 0
- Recommendation Working Distance Range [mm] 327 - ∞
- Minimum Working Distance without Extension Tubes [mm] 155
- Filter Thread [mm] M43 x 0.75
- F'eff [mm] 51.21
- SF [mm] -23.75
- S'F' [mm] 32.17
- HH' [mm] -10.90
- ß'P 1.07
- SEP [mm] 23.94
- S'AP [mm] -22.81
- Σd [mm] 35.59
- Net Weight [Standard] [g] 196
