| Cellular Perfomance | 4G - LTE Category 4 |
| Cellular Fallback | 3G - HSPA +, 2G - GPRS |
| Frequency Band (MHz) | - 4G FDD: B1(2100), B2(1900), B3(1800),
- B4(AWS1700), B5(850), B7(2600),
- B8(900), B12/B13(700), B18(850), B19(850),
- B20(800), B25(1900), B26(850), B28(700) 4G TDD: B38(2600), B39(1900), B40(2300), B41(2500)
- 3G: B1(2100), B2(1900), B4(AWS1700),
- B5(850), B6(800), B8(900), B19(850)
- 2G: B2(1900), B3(1800), B5(850), B8(900)
|
| Packet Data* | - 4G-FDD: Up to 150 Mbps peak downlink. Up to 50 Mbps peak uplink
- 4G-TDD: Up to 130 Mbps peak downlink. Up to 30 Mbps peak uplink
|
| Diversity/MIMO | Rx Diversity and MIMO DL 2x2 |
| SMS | - Point-to-Point Messaging
- Mobile-Terminated SMS
- Mobile-Originated SMS
|
| Input Voltage | 7V to 32VDC |
| Wi-Fi/Bluetooth (-B10 Models) | Wi-Fi: 802.11abng (2.4 & 5 GHz) Bluetooth: Classic 4.1 and BLE |
| GPS/GNSS (-B10 Models) | - GNSS connections: 3
- GNSS Systems Supported: (default: concurrent GPS/QZSS/SBAS and GLONASS)
|
| LEDs | - POWER / STATUS
- Modem: CD LED (Carrier Detect), LS LED (Link Status)
- Signal Strength: 3 LEDs
- Ethernet: Link, Speed
- Wi-Fi (-B10 models only)
|
| CELL1, CELL2 | (2) Female SMA (Cellular Antenna) |
| WIFI (-B10 Models only) | Reverse polarity female SMA (Wi-Fi/BT Antenna) |
| GPS (-B10 Models only) | Female SMA (GPS Antenna) |
| SIM | Micro SIM Card (3FF); 1.8V and 3V |
| E-NET | Ethernet RJ-45, 10/100 BaseT |
| RS-232 | DE9 (Serial Connection) |
| Power | 2.5 mm miniature (screw-on) |
| Dimensions (L x W x H) | 4.17" x 3.0" x 1.15" (10.6 cm x 7.6 cm x 2.9 cm) |
| Weight | 0.51 lbs (0.231 Kg) |
| Chassis Type | Anodized aluminum (blue) / (IP-Rating: Designed for IP30) |
| Operating Temperature† | -40° to +176° F (-40° to +80° C) |
| Storage Temperature | -40° to +185° F (-40° to +85° C) |
| Humidity | Relative humidity 15% to 93% noncondensing |
| EMC Compliance | - Australia/New Zealand: CISPR 32 Canada: ICES-003 Class B Europe: CE Mark, UKCA,
- EN 55032:2012/AC:2013 (Emissions),
- EN 55032:2015+A11:2020, EN 55024:2010 (Immunity)
- US: FCC Part 15 Class B
|
| Radio Compliance | - Australia/New Zealand: AS/NZS 4268:2012 + A1:2013 MPE Standard 2014
- Europe:
- RED, Article 3.1b EN 301 489-1 V2.2.3
- EN 301 489-17 V3.1.1 (-B10 models only) EN 301 489-19 V2.1.0 (-B10 models only) EN 301 489-52 V1.1.0
- RED, Article 3.2
- EN 303 413 V1.1.1 :2017 (-B10 models only)
- EN 300 328 V2.2.2 (-B10 models only) EN 301 511 V12.5.1 :2017
- EN 301 893 V2.1.1 :2017 (-B10 models only)
- EN 301 908-1 V13.1.1
- EN 301 908-2 V13.1.1
- EN 301 908-13 V13.1.1
- MPE/RF Exposure: EN 62311:2008
- Canada: ISED
- US: FCC Part 22, 24, 27
|
| Safety | - Australia/New Zealand: AS/NZS 60950-1
- Canada: cUL 60950-1, cUL 62368-1
- Europe: IEC 60950-1, IEC 62368-1
- US: UL/ 60950-1, UL62368-1
|
| Additional Regulatory Approvals Available (Contact MultiTech for details) | - Anatel (Brazil), IFETEL (Mexico), SRRC/CCC/NAL (China), KC (South Korea), NCC (Taiwan, China), JATE/TELEC (Japan), FAC (Russia), NBTC (Thailand),
- IMDA (Singapore), ICASA (South Africa)
|
| Mobile Network Operator Approvals | - Australia: RCM, Optus, Telstra, Vodafone Europe: GCF Approved Module, European Network Operators
- US: PTCRB, AT&T, Verizon
|
| Additional Mobile Network Operator Certifications Available (Contact MultiTech for Details) | - Canada: Rogers, Telus
- US: T-Mobile, US Cellular
|
| Quality | - MIL-STD-810G: High Temp, Low Temp, Random Vibration
- SAE J1455: Transit Drop & Handling Drop, Random Vibration, Swept-Sine Vibration IEC68-2-1: Cold Temp
- IEC68-2-2: Dry Heat
|
- * Actual performance speeds may be affected by a variety of attributes such as cell tower distance, data loads, packet sizes, etc.
- Device has been tested up to +85° C. UL Recognized @ 40° C, limited by AC power supply. UL Recognized @ 60° C when used with the fused DC power cable, part number FPC-532-DC.
|
