BWI Eagle 441-20100-AC Air-Eagle XLT 900MHz RF Receiver 2500 Ft
Brand NewChoose Type
Manufacturer warranty Description
The Air-Eagle XLT is an RF system designed for short to medium range wireless remote control of electrical apparatus in a variety of industrial applications. Systems can consist of any number of receivers and handheld or contact input transmitters working together. This receiver is equipped with single relay can switch 5 amps at 120VAC or 30VDC. The relay is user programmable for momentary, toggle/latching or latching operation and can be directly interfaced with the customer's equipment or P.L.C. Eight user selectable frequencies allow multiple systems to be used in the same area. The Air-Eagle XLT can receive remote signals transmitted from up to 2500 feet away (with a handheld transmitter) or upto 2 miles away (with a stationary transmitter and external antennas).
For more information, please see
Data Sheet
Technical details
- Weight Approx 2 lbs
- Enclosure Polycarbonate NEMA 4, 12, 13 – IP66
- Type Receiver
- Operating Temperature -40°F to +185°F
- AC Input 100-250 VAC, 5W, 50/60 Hz
- Relay Contact SPDT 5 amp at 120VAC or 30VDC
- Fuse Protected 1 amp
- Receiver Frequency 900 MHz Spread Spectrum
- Receiver Range Up to 2500 feet with standard antenna
- RF Networks Eight Independent Frequencies
