| Dimensions | 12" x 9.6" |
| CPU | Supports 3rd Gen Intel ® Xeon ® Scalable processors |
| socket | Single Socket P+ (LGA 4189) |
| Chipset | Intel® C621A |
| Capacity | 8 DIMM slots (1DPC) |
| Type | Supports DDR4 288-pin RDIMM, LRDIMM, RDIMM/LRDIMM-3DS, Intel ® Optane™ Persistent Memory 200 series |
| DIMM Size Per DIMM | - RDIMM: up to 64GB
- RDIMM-3DS: up to 256GB
- LRDIMM: up to 128GB
- LRDIMM-3DS: up to 256GB
|
| Max. DIMM Frequency | max. 3200MHz |
| Voltage | 1.2V |
| PCIe x 16 | - SLOT7: PCIe4.0 x16
- SLOT5: PCIe4.0 x16
- SLOT3: PCIe4.0 x16
- SLOT1: PCIe4.0 x16
|
| PCIe x 8 | - SLOT6: PCIe4.0 x8
- SLOT4: PCIe4.0 x8
- SLOT2: PCIe4.0 x8
|
| SATA Controller | - Intel ® C621A (13 SATA 6Gb/s; RAID 0/1/5/10):
- 1 Mini-SAS HD, 6 SATA 7-pin, 2 SATA DOM, 1 M.2
|
| M.2 slot | - 1 M-key (PCIe3.0 x4), supports 22110/2280/2242 form factor
- 1 M-key (PCIe3.0 x1 or SATA 6Gb/s), supports 22110/2280/2242 form factor
|
| Additional GbE Controller | Intel® i210 : 2 RJ45 (1GbE) |
| BMC Controller | ASPEED AST2500 |
| IPMI Dedicated GLAN | 1 x Realtek RTL8211E for dedicated management GLAN |
| Controller | ASPEED AST2500 |
| VRAM | DDR4 16MB |
| VGA Port | 1 DB15 |
| USB 3.0 Port | 4 Type-A (USB3.2 Gen1) |
| Lan Port | 2 RJ45 (1GbE) |
| UID Button/UID LED | One |
| Power Connector | 1 (24-pin, ATX main power), 1 (8-pin, ATX 12V), 1 (4-pin, ATX 12V), 1 (3-pin, SATA power) |
| COM Header | One |
| Auxiliary Panel Header | 1 (18-pin): chassis intrusion, system fault LED, LAN1/LAN2 activity LED, locate, SMBus |
| TPM Header | 1 (17-pin, LPC), 1 (13-pin, SPI) |
| Thermal Sensor Header | One |
| IPMB Header | One |
| VGA Header | One |
| Fan Header | 5 (6-pin) |
| USB 3.2 (Gen1) Header | 1 (19-pin, 2 USB3.2 Gen1) |
| USB 2.0 Header | 1 (9-pin, 2 USB2.0) |
| Type A USB 2.0 Port | 1 (Type-A, 1 USB2.0) |
| NMI Header | One |
| System Panel | 1 (9-pin): power switch, reset switch, system power LED, HDD activity LED |
| Speaker Header | One |
| BMC_SMB Header | One |
| SGPIO Header | One |
| VROC KEY | One |
| Clear CMOS | 1 (contact pads) |
| ME/SPS Recovery | One |
| NC-SI | One |
| Standby PWR LED 5vsb | One |
| Port 80 LED | One |
| Fan Fail LED | 5 |
| BIOS Type | 256Mb SPI Flash ROM |
| BIOS Features | AMI UEFI BIOS |
| Temperature | CPU, PCH, MB, Card side Temperature Sensing |
| Fan | - CPU/Rear/Front Fan Tachometer
- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU Temperature)
- CPU/Rear/Front Fan Multi-Speed Control
|
| OS | - Microsoft ® Windows ® :
- Server 2016 (64 bit)
- Server 2019 (64 bit)
- Linux :
- Red Hat Enterprise Linux Server 7.9 (64 bit) / 8.3 (64 bit)
- CentOs 7.9 (64 bit) / 8.3 (64 bit)
- SUSE Enterprise Linux Server 12 SP5 (64 bit) / 15 SP2 (64 bit)
- Ubuntu 20.04.1 (64 bit) / 20.10 (64 bit)
- Hypervisor :
- VMWare ® ESXi 6.7 U3 / vSphere 6.7 U3
- VMWare ® ESXi 7.0.U1c / vSphere 7.0.U1c
- Hyper-V Winders Server 2016
- Hyper-V Winders Server 2019
|
| Temperature | Operation temperature: 10°C ~ 35°C / Non operation temperature: -40°C ~ 70°C |
| Humidity | Non operation humidity: 20% to 90% ( Non condensing) |
