| System |
| Form Factor | 3U Rackmount |
| Chassis Model | 3U8G+ |
| Dimensions | 711 x 430 x 130.5 mm (27.6 x 16.9 x5.1 inches) |
| Support MB | CEB, 12''x10.5" (EP2C612D16FM2) |
| Front Panel |
| Buttons | Power On/Standby button ID button System reset button NMI button |
| LEDs | Power LED Identification LED Hard drive activity LED 4x Network activity LEDs System event LED |
| I/O Ports | 1 x VGA port 2 x USB 2.0 ports |
| External Drive Bay / Storage |
| Front Side Drive Bay | 6 Bay 2.5" SATA HDD (6Gb/s) |
| Power Supply |
| Type | 4 (3+1), Redundant |
| Output Watts | 1200W |
| System Fan |
| Fan | 80 x 38 mm x 8 |
| System Switch board |
| Switch IC | PLX 8747 x4 |
| Supports GPU Card | 8pcs double width GPU card (x16) |
| GPGPU card |
| GPGPU Watts | Max 300w /per card |
| Support GPGPU | 8 x GPGPU card |
| Physical Status |
| Form Factor | SSI CEB |
| Dimensions | 12'' x 10.5'' (30.5 cm x 26.7 cm) |
| Processor System |
| CPU | Intel® Xeon®processor E5-2600 v3/v4 series |
| Socket | Dual Socket LGA 2011 R3 |
| Chipset | Intel® C612 |
| System Memory |
| Capacity | 16 DIMM slots |
| Type | Quad Channel memory technology Support DDR4 2400/2133/1866/1600 R DIMM and LRDIMM |
| Voltage | 1.2V |
| Additional PCIe switch | Front Right Angle 2 x16 from each CPU to Midplane, total 4 x16 (need to bundle with ASRock Rack system board) |
| Storage |
| SATA Controller | Intel® C612 : 6 x SATA3 6.0 Gb/s (4 from 1 mini SAS connector + 2x SATA3 connector) |
| Ethernet |
| Interface | 1000 /100 /10 Mbps |
| LAN Controller | 2 x RJ45 by Intel® i350 1 x RJ45 Dedicated IPMI LAN port Supports Wake-On-LAN Supports Energy Efficient Ethernet 802.3az Supports Dual LAN with Teaming function Supports PXE Supports SR-IOV LAN1 Supports NCSI |
| Mezzanine | 2 x 8 Mezzanine slot support mezzanine card or 2 x PCIE cards. Supports NCSI |
| Management |
| BMC Controller | ASPEED AST2400 |
| IPMI Dedicated GLAN | 1 x Realtek RTL8211E for dedicated management GLAN |
| Features | Watch Dog NMI |
| Graphics |
| Controller | ASPEED AST2400 |
| VRAM | DDR3 16MB |
| Rear Panel I/O |
| VGA Port | 1 x D-Sub |
| USB 2.0 Port | 2 |
| USB 3.2 Gen1 Port | 2 |
| Lan Port | 2 + 1 (IPMI) Lan port (RJ45) LAN Ports with LED (ACT/LINK LED and SPEED LED) |
| Serial Port | 1 (COM1) |
| UID Button/UID LED | 1 |
| Internal Connector |
| Auxiliary Panel Header | 1 (includes chassis intrusion, location button & LED, front LAN LED) |
| TPM Header | 1 |
| IPMB Header | 1 |
| Fan Header | 2x CPU Fan, 6x system Fan (4-pin) |
| ATX Power | 1 (24-pin) + 2 (8-pin) |
| USB 3.2 (Gen1) Header | 1 (support 2 USB 3.0) |
| USB 2.0 Header | 1 (support 2 USB 2.0) |
| Type A USB 3.2 (Gen1) Port | 1 |
| Front Panel | 1 |
| Mezzanine | 2 (x8 mode from CPU1 ; x8 mode from CPU2) |
| System BIOS |
| BIOS Type | 128Mb AMI UEFI Legal BIOS |
| BIOS Features | Plug and Play (PnP) ACPI 2.0 Compliance Wake Up Events SMBIOS 2.8 Support ASRock Rack Instant Flash |
| Hardware Monitor |
| Temperature | CPU Temperature Sensing System Temperature Sensing Card Side Temperature Sensing |
| Fan | CPU/Rear/Front Fan Tachometer CPU Quiet Fan (Allow CPU Fan Speed Auto-Adjust by CPU Temperature) CPU/Rear/Front Fan Multi-Speed Control |
| Voltage | Voltage Monitoring: CPU1/2, VCCM_AB/CD/EF/GH, +1.50_ PCH, 3V/5V/ 12V, +1.05V_PCH, +BAT, 3VSB, 5VSB |
| Environment |
| Temperature | Operation temperature: 10°C ~ 35°C / Non operation temperature: -40°C ~ 70°C |
