| Video/Audio Input |
| IP Video Input | 32-ch |
| Two-way Audio Input | 1-ch, RCA |
| Network |
| Incoming Bandwidth | 320Mbps |
| Outgoing Bandwidth | 160Mbps |
| Remote Users | 128 |
| Protocols | TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP |
| Browser | - IE(IE10/11) for Windows
- Firefox (version 52.0 and above) for Windows
- Chrome(version 45 and above) for Windows
- Edge(version 79 and above) for Windows
|
| Video/Audio Output |
| HDMI/VGA Output | - HDMI:
- 4K(3840x2160)/30Hz
- 1920x1080p/60Hz
- 1920x1080p/50Hz
- 1600x1200/60Hz
- 1280x1024/60Hz
- 1280x720/60Hz
- 1024x768/60Hz
- VGA:
- 1920x1080p/60Hz
- 1920x1080p/50Hz
- 1600x1200/60Hz
- 1280x1024/60Hz
- 1280x720/60Hz
- 1024x768/60Hz
|
| Recording Resolution | 16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Audio Output | 1-ch, RCA |
| Two-way Audio | 1-ch, RCA(Using the audio input and output) |
| Audio Compression | G.711A, G.711U |
| Synchronous Playback | 16-ch |
| Liveview display | 1/4/6/8/9/16/25/32 |
| Corridor Mode Screen | 3/4/5/7/9/10/12/16/32 |
| Snapshot |
| FTP/Schedule/Event Snapshot | 4-ch snapshot, up to D1 resolution |
| Decoding |
| Decoding format | Ultra 265/H.265/H.264 |
| Liveview/Playback | 16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Capability | - Ultra 265/H.265: 2 x 16MP at 30, 2 x 12MP at 30, 4 x 4K at 30, 6 x 5MP at 30, 8 x 4MP at 30, 10 x 3MP at 30, 16 x 1080P at 30, 32 x 960P at 25
- H.264: 2 x 16MP(4800 x 2688) at 30, 2 x 12MP at 30, 2 x 4K at 30, 4 x 5MP at 30, 6 x 4MP at 30, 8 x 3MP at 30, 14 x 1080P at 30, 30 x 720P at 30, 32 x D1
|
| Hard Disk |
| SATA | 2 SATA interfaces |
| Capacity | Up to 8TB for each disk (The maximum HDD capacity varies with environment temperature) |
| Smart |
| VCA Detection by Camera | Vehicle Detection, Intrusion Detection, Cross Line Detection, Enter Area, Leave Area, Temperature Detection(Fire Detection, Smoking Detection, Temperature Measurement, Smoke and Fire Detection), UMD(Ultra Motion Detection), Video Metadata, Traffic Monitoring |
| VCA Search | Motor Vehicle Search, Non-Motor Vehicle Search, Human Body Search, General Search, People Counting Report |
| People counting | People Flow Counting, Crowd Density Monitoring |
| Smart Intrusion Prevention (SIP), UMD by Camera | Total 8-ch |
| General Alarm |
| General Alarm | Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed, Auto Tracking, Motion, Tampering, Human Body Detection, Video Loss, Alarm Input, Audio Detection |
| Alert Alarm | IP Conflict, Network Disconnected, Disk Offline , Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal |
| External Interface |
| Network Interface | 2 RJ-45 10M/100M/1000M self-adaptive Ethernet Internetface |
| USB Interface | Front: 1 x USB2.0, Rear panel: 1 x USB3.0, 1 x USB2.0 |
| RS485 | 1 |
| Alarm In | 8-ch |
| Alarm Out | 2-ch |
| General |
| Power Supply | - 12V DC/3.3A
- Power Consumption: ≤ 20W (without HDD)
|
| Working Environment | -10°C~+ 55°C (+14°F~+131°F), Humidity ≤ 90% RH (non-condensing) |
| Dimensions (WxDxH) | 380mm x 322mm x 53mm (15.0"x12.7"x2.1") |
| Weight (without HDD) | ≤ 2Kg (4.40lb) |
| Certification |
| Certification | CE, FCC, UL, RoHS, WEEE |
| CE | EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035 |
| FCC | Part15 Subpart B |
