Transtector
AC Surge Protector, SPD, DIN-Rail, 277 Vac

Transtector I2R-75KS277 AC Surge Protector, SPD, DIN-Rail, 277 Vac

Part #:
I2R-75KS277
Condition:
Brand New

Choose Service Voltages (Vac)

Contact Us For Pricing
Check availability
Contact Us For Pricing
Manufacturer warranty

Description

Contact Us For Pricing
Check availability

Technical details

Main features
  • Certifications UL 1449 4th Ed. Type 1 and Type 2
  • Frequency Minimum: 50 Hz Maximum: 60 Hz
  • TAA Compliant Yes
  • Service Voltages (Vac) 277
  • Housing Material and Plating PA66 CT1; V-0
  • Service Type Single-phase
  • Environmental Protection Rating IP20
  • Protection Modes L-N
  • Mount Type DIN Rail
  • Response Time 25 ns
  • Humidity 95% Non-Condensing
  • Indoor/Outdoor Indoor
  • Surge Protection Technology MOV
  • 8/20µs Surge Current 75 kA
  • Nominal Discharge Current Rating (In) 20 kA
  • UL Compliant Yes
  • Maximum Continuous Operating Voltage (MCOV) L-N: 320 Vac
  • VPR 8/20µs L-N: 1,200 Vpk
  • Temperature Range (Operational) -40 to +85 deg C
  • Service Voltages 277 Vac
  • SCCR (Short Circuit Current Rating) 200 kAIC
  • Temperature Range (Storage) -40 to +85 deg C
  • Service Wiring Terminal Compression Lug: #4 to #14 AWG
  • Status Indication Terminal 3-Position Screw Terminal: #16 to #22 AWG
