Thor Broadcast F-SattGalaxy-TX/RX-5 RF Transmitter and Receiver Kit

Part #:
F-SattGalaxy-TX/RX-5
Condition:
Brand New

Choose Number of RF Inputs

$3,601.00 /Kit
$4,794.00 You save $1,193.00 25%
Free shipping
3-4 Weeks Factory Lead Time
Check availability
$3,601.00 /Kit
$4,794.00 You save $1,193.00 25%
Manufacturer warranty

Description

$3,601.00 /Kit
$4,794.00 You save $1,193.00 25%
Free shipping
3-4 Weeks Factory Lead Time
Check availability

Technical details

Main features
  • Number of RF Inputs 5
  • RF Connectors F-Type
  • Optical connector SC/APC
  • Power consumption [W] < 15, < 10
  • Input frequency range [MHz] 47-2150
  • RF inputs-signal level [dBµV] 75±10
  • Power transmission for LNB 13/18 V (350 mA)
  • Impedance [Ω] 75
  • Optical output power [dBm] +2 to +10 Model Dependent
  • SAT/DVB-T transmission window III (VL: 1510 nm, HL: 1530 nm, VH+Terr: 1550 nm, HH: 1570 nm)
  • Supply voltage [VDC] 20
  • Operating temperature range [°C] -10...+40
  • Dimensions [mm] / In 195x128x40 / 7.7"x 5" x 1.57", 195x128x40mm / 7.7" x 5" x 1.57"
  • Output frequency range [MHz 47-2150
  • RF Output-signal level [dBµV] 75±10 AGC
  • Input signal level (optical) [dBm] -14... + 3 (AGC range:-7...2)
  • AGC efficiency [dB] ±1
  • SAT/DVB-T transmission CWDM wavelengths III (VL: 1510 nm, HL: 1530 nm, VH+Terr: 1550 nm, HH: 1570 nm)
