Load Capacity (Ton) x Stroke Size (in):: Load Capacity (Ton) x Stroke Size (in): 10 x 1-1/2

SPX Power Team, RSS101, Shorty 10 Ton Capacity 1-1/2" Stroke Single Acting Cylinder

Features:

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Retracted Height (in. [mm])	3.50 [88,9]
Extended Height (in. [mm])	5.00 [127,0]
Outside Diameter (in. [mm])	2.75 [69,9]
Base to Port (in. [mm])	0.63 [15,9]
Piston Rod Diameter (in. [mm])	1.50 [38,1]
Bore Diameter (in. [mm])	1.69 [42,9]
Cylinder Capacity (tons)	10
Cylinder Effective Area - Push (sq. in. [cm²]	2.24 [14,4]
Internal Pressure at Capacity - Push (psi)	8943
Oil Capacity - Push (cu. in. [cm³])	3.40 [56,0]
Oil Capacity - Return (cu. in. [cm³])	-
Stroke (in. [mm])	1.50 [38,1]
Tons at 10,000 psi - Push [Metric Tons at 700 bar - Push]	11.20 [10,2]
Weight (lbs. [kg])	6.00 [2,7]

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Retracted Height (in. [mm])	3.50 [88,9]
Extended Height (in. [mm])	5.00 [127,0]
Outside Diameter (in. [mm])	2.75 [69,9]
Base to Port (in. [mm])	0.63 [15,9]
Piston Rod Diameter (in. [mm])	1.50 [38,1]
Bore Diameter (in. [mm])	1.69 [42,9]
Cylinder Capacity (tons)	10
Cylinder Effective Area - Push (sq. in. [cm²]	2.24 [14,4]
Internal Pressure at Capacity - Push (psi)	8943
Oil Capacity - Push (cu. in. [cm³])	3.40 [56,0]
Oil Capacity - Return (cu. in. [cm³])	-
Stroke (in. [mm])	1.50 [38,1]
Tons at 10,000 psi - Push [Metric Tons at 700 bar - Push]	11.20 [10,2]
Weight (lbs. [kg])	6.00 [2,7]

Note: Please read description carefully. Do not base your order on the picture presented.
