Buy SPX Power Team 9120A, Bottle Jack, 20 Ton, 6-1/4" Stroke

info@PrimeBuy.com

1-855-969-9322
1-908-282-3332 (Intl.)

Options and Related Products

Features:

Choose from this complete line of premium-quality bottle jacks. Ideal for use in any number of industrial lifting and pushing applications.
The 9110B, 9015B, 9022B and 9033B feature a beveled base which allows the jack to "follow" the load, reducing the chance of dangerous side-loading.
Jacks feature a screw extension for quicker setup.
High-strength piston and pump linkage for long life.
All models include over-travel protection.
Lever Bar included on all models. All jacks can be used in the vertical, angled or horizontal positions.
Serrated or contoured saddles help stabilize the load for a safer lift.
110-ton jack features dual pumps for time-saving two-speed operation.
All jacks meet ASME B30.1 standards

Ideal for industrial lifting and pushing applications for MRO.

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Capacity (tons)	20
Stroke in)	6.25
Retracted Height Min. (in)	10.63
Length of Screw Ext. (in)	3.63
Height with Screw Ext. (in)	20.50
No. Pump Strokes to Ext. Piston	22
Saddle Dia. (in)	2.00
Base Size (in)	7.19 x 5.06
Pump Handle Length (in)	31.5
Handle Effort at Rated Cap. (lbs)	70
Carry Handle	Yes
weight (lbs)	28.50

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Capacity (tons)	20
Stroke in)	6.25
Retracted Height Min. (in)	10.63
Length of Screw Ext. (in)	3.63
Height with Screw Ext. (in)	20.50
No. Pump Strokes to Ext. Piston	22
Saddle Dia. (in)	2.00
Base Size (in)	7.19 x 5.06
Pump Handle Length (in)	31.5
Handle Effort at Rated Cap. (lbs)	70
Carry Handle	Yes
weight (lbs)	28.50

Note: Please read description carefully. Do not base your order on the picture presented.
