Siemens, SKB82.50U, Flowrite Electro-Hydraulic Actuator, Float Control, NSR, 3/4" Stroke

Features:

The Flowrite SKB Valve Actuator is used with Flowrite and other standard valves with a 3/4-inch stroke.
This electronic valve actuator requires a 24 Vac supply to provide floating control of the valve.
Other features of this valve actuator include automatic stroke calibration, manual override, die-cast aluminum housing, 1000 lb (4000N) thrust, and non-spring return functionality.

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Ambient temperature, operation	-15 - 55 °C
Degree of protection	IP54
Dimensions (W x H x D)	7.01 x 14.84 x 8.94 in
Medium temperature	-25 - 220 °C; 5 - 130 °F
Mounting position	NEMA 1 (interior only), Upright
Operating voltage	19.2 - 28.2 V24 V#AC
Position feedback	None
Positioning signal	3-position
Positioning time	120 s
Spring return function	Non-spring return functionality
Stroke	20 mm
Positioning force	4400 N
