Options and Related Products

Amperage:: Amperage: 800A

Features:

Split-core rogowski coil is lightweight and space saving
Universal output reduces inventory
No call backs due to mis-sizing
Compatible with any control Applications

Applications:

Load trending
Building mains
Motor control
Process control
Chiller monitoring

Rogowski analog transducers measure high amperage AC current and provide a proportional output for load trending and control. Rowgoski coil overs wide amperages without saturation effects common to iron core sensors. Selectable ranges ensure excellent resolution.

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

Amperage

800A

Output type

Universal (2-wire 4-20mA, 3-wire 0-5V/0-10V/4-20mA)

Accuracy

+/-2% F.S. over 10 to 100% range

Temperature rating

Maximum surrounding air ambient, 60 ° C

Sensor Power

12 to 30VDC/24VAC

Frequency Range

50/60Hz

Dimensions ( LxWxH)

3.5" x 1.6" x 0.8"

Insulation class

600V RMS. For use on insulated conductors only
Use minimum 75 ° C insulated conductors
Must be installed at least 1/2" away from any uninsulated conductor
This product provides basic insulation only
