| Video Streams | - Streams 1 & 2:
- Codec: H.264 High, Level 5 / MJPEG (both streams configurable)
- Compression Level: Multi-levels of compression adjustment
- Pixel Resolution: Fisheyes at 0.25 MP (528 x 480), 1 MP (1056 x 960), 2 MP (1488 x 1360), 4 MP (2144 x 1944)
- Stream 3:
- Codec: MJPEG
- Compression Level: Multi-levels of compression and frame rate adjustment (maximum 15 fps)
- Pixel Resolution: Fisheye at 0.25 MP (528 x 480)
|
| Image Controls | Settings: brightness/contrast/saturation/exposure compensation; compression quality; wall/ceiling/table mount |
| Image Enhancement | Wide Dynamic range; greater than 90 db |
| VMS Software | Integrated with Digital Sentry version 7.5 and other leading VMS platforms |
| Web Browser | Internet Explorer IE9 (with ActiveX plug-in, supplied); Firefox 23 ; Chrome 29; using QuickTime, minimum version 7 |
| Number of Users | Unicast: Up to 20 simultaneous users depending on the resolutions settings |
| Bit Rate | Selectable options; constant bit rate control, capped bit rate control, constant quality control |
| Image Sensor | 5 MP (H x V: 2592 x 1944); array format (active); 1/2.5" CMOS Sensor |
| Field of View | 360° |
| Angle of View | 180° hemisphere |
| Lens | 185°; 1.6 mm; f/2.0 |
| Minimum Illumination | 0.2 lux; 50 IRE, f/2.0 (6500 K) |
| Frame Rate | 10 fps typical at maximum resolution and up to 15 fps for all other resolutions |
| Video Motion Detection | 12 regions of interest; VMD; configurable response; adjustable characteristics |
| Storage | - H.264:
- at4 MP (2144 x 1944); 10 fps; constant bit rate (5 Mb/s): 54 GB
- at2 MP (1488 x 1360); 15 fps; constant bit rate (3 Mb/s): 40 GB
- at1 MP (1056 x 1056); 15 fps; constant bit rate (1.5 Mb/s): 16 GB
- at0.25 MP (528 x 480); 15 fps; constant bit rate (0.8 Mb/s): 8 GB
- MJPEG:
- at4 MP (2144 x 1944); 10 fps; average file size: 640 kB, average bit rate: 52.4 Mb/s: 552.96 GB
- at2 MP (1488 x 1360); 15 fps; average file size: 350 kB, average bit rate: 43.0 Mb/s: 453.60 GB
- at1 MP (1056 x 1056); 15 fps; average file size: 188 kB, average bit rate: 23.1 Mb/s: 243.65 GB
- at0.25 MP (528 x 480); 15 fps; average file size: 62 kB, average bit rate: 7.6 Mb/s: 80.35 GB
|
| External | - 1 x contact input
- 1 x contact output
|
| Security | Configurable password protection |
| Advanced Event Management | Triggered by motion, external input or HTTP event, result configurable; external output, FTP/SMTP upload, (local recording, future feature via firmware update) |
| Networking | TCP/IP, HTTP, DHCP, DNS, NTP, FTP, SMTP, RSTP, uPNP |
| Privacy | 10 configurable privacy regions |
| SD Card | Built-in SD Card slot (future feature via firmware update) |
| Audio Connections | Audio in; microphone input via 3.5 mm jack; via RTSP using G711 codec (µ law - 8k sample rate); via ONVIF S |
| Analog Video Out | BNC connection - selectable between PAL or NTSC (used for test only) |
| Signal-to-Noise Ratio | 45 dB |
| Auto White Balance Range | Auto white balance (range = approximately 2500 to 8000 K) |
| Supports | Oncam Grandeye SDK integration pack, Evolution accessories, IP Configuration tool, 360° viewer, OnVu360 Mobile Apps (iOS, Android) |
| Processor & Memory | Computer with 1 GHZ 32-bit (x86) or 64-bit (x64) processor and with minimum of 512 MB |
| Operating System | Windows Vista 32-bit with service pack 2 (SP2) of higher / 64-bit with service pack (SP2) of higher |
| Hard Drive Space | - Windows Vista 32-bit = minimum 70 MB
- Windows Vista 64-bit = minimum 120 MB
|
| Display | Super VGA (800 x 600) of higher-resolution monitor with 256 colors |
| Peripherals Supported | 100 Mb or greater network connection, mouse or compatible pointing device, keyboard |
| Ports | RJ45 for 100Base-TX; 2.1 mm DC Input jack; 6-pin 1.5 mm Phoenix for external I/O, BNC for test video output |
| Network Cable Type | CAT5 or better for 100Base-TX |
| Power Input | 12 V, 1 A (minimum) "LPS or NEC Class 2" power supply or Power over Ethernet (PoE), IEEE standard 802.3af |
| Power Consumption | 8 W maximum |
| Approvals | IEEE802.3af Class 2; EMC: (CISPR Class A) FCC; CE; ICES-003; KCC; SASO; GOST; S-MARK; C-TICK; UL and cUL-UL60950 |
| Shock and Vibration | In accordance with BS EN 60068-2-64 and BS EN 60068-2-27 |
| Ingress protection | IP66-rated |
| Impact Resistance | IK10-rated |
| Camera Mount | Surface mount (or with a range of mounting accessories for mounting to a pole / wall / pendant) |
| Enclosure | Aluminum die-cast base enclosure with clear polycarbonate dome bubble and cover trim plate |
| Operating Temperature Range | -40 to 131°F (-40 to 55°C) |
| Storage Temperature Range | -40 to 158°F (-40 to 70°C) |
| Operating Humidity | Up to 98% (in accordance with BS EN 60068-2-30) |
| Dimensions | 6.97 x 6.22 x 3.86" (17.70 x 15.79 x 9.80 cm) |
| Weight | 2.03 lb (0.92 kg) |
| Package Weight | 1.4 lb |
| Box Dimensions (LxWxH) | 9.9 x 6.3 x 5.1" |
