DC |
Measuring range | Resolution/Accuracy |
4V DC | 1 mV/+- (1.2% of measured value + 2 digits) |
40V DC | 10 mV/+- (1.5% of measured value + 2 digits) |
400V DC | 100 mV/+- (1.5% of measured value + 2 digits) |
600V DC | 1V/+- (2% of measured value + 2 digits) |
Input impedance | 10 M |
Overvoltage protection | 600V DC600V AC RMS |
AC |
Measuring range | Resolution/Accuracy |
4V AC | 1 mV/+- (1.5% of measured value + 5 digits) |
40V AC | 10 mV/+- (1.5% of measured value + 2 digits) |
400V AC | 100 mV/+- (1.5% of measured value + 2 digits) |
600V AC | 1V/+- (2% of measured value + 2 digits) |
Input impedance | 10 M |
Overvoltage protection | 600V DC600V AC RMS |
Frequency range | 50 - 400 Hz |
Alternating current |
Measuring range | Resolution/Accuracy |
200 A AC | 100-mA/+- (3.0% of measured value + 5 digits) |
Overload protection | 200 A AC |
Frequency range | 50 - 60 Hz |
Resistance |
Measuring range | Resolution/Accuracy |
400 | 0.1/+- (1% of measured value + 4 digits) |
4 k | 1/+- (1.5% of measured value + 4 digits) |
40 k | 10/+- (1.5% of measured value + 4 digits) |
400 k | 100/+- (1.5% of measured value + 4 digits) |
4 M | 1 k/+- (2.5% of measured value + 4 digits) |
40 M | 10 k/+- (3.5% of measured value + 4 digits) |
Overvoltage protection | 250V DC |
Connection thermocouple | Type K connection with adapter |
Capacity |
Measuring range | Resolution/Accuracy |
4 nF | 0.1 nF/+- (5% of measured value + 20 digits) |
40 nF | 1 nF/+- (3% of measured value + 5 digits) |
400 nF | 10 nF/+- (3% of measured value + 5 digits) |
4 uF | 100 nF/+- (3% of measured value + 5 digits) |
40 uF | 1 uF/+- (3% of measured value + 5 digits) |
100 uF | 10 uF/+- (3% of measured value + 10 digits) |
Overvoltage protection | 250V DC250 AC; RMS |
Check feature | Test/Display |
Diode test | Test current: 0.5-mAReverse Voltage: 1.5V/Forward voltage of the diode |
Continuity test | Open circuit Voltage 0.5V/Noise when resistance<50 |
Overvoltage protection | 250V DC250 AC RMS |
General technical specifications |
Jaw Capacity | About 17 mm / .7 in |
Display | 4000 digit LCD with backlight |
Continuity test | Noise when resistance<50 |
Test current | About 0.5-mA |
Open circuit voltage | < 2V DC |
Battery indicator | Battery icon when battery voltage low |
Display overrange | OL appears in the display |
Refresh rate display | 3 Hz |
Temperature sensor | Thermocouple type K |
Input impedance | 10 M |
Operating conditions | 5 - 40°C / 41 - 104°F, 80% rh non-condensing |
Storage conditions | -20 - 60°C / -4 - 140°F, 80% rh non-condensing |
Operating altitude | < 2000 m / 6561 ft |
Power supply | 2 x 1.5V AAA battery |
Automatic shutdown | 30 minutes |
Security conditions | IEC1010-1 (2001)CAT II 1000VCAT III 600V |
Pollution degree | 2 |
