Network Technologies (NTI) st-ipusbvd-l-vw VGA/DVI USB KVM Extender
Brand:
Network Technologies (NTI)
Part #:
st-ipusbvd-l-vw
Condition:
Brand New
Brand New $479.80 /Each
Manufacturer warranty Description
Network Technologies, st-ipusbvd-l-vw, VGA/DVI USB KVM Extender Over IP with Video Wall Support, Local Unit
Features:
- Supports HDTV resolutions to 1080p, and up to 1920x1200 (WUXGA) at 60Hz.
- Extend up to 492 feet (150 meters) in a Point-to-Point connection.
- Extend up to 656 feet (200 meters) in a Point-to-Point or Point-to-Many connection via a Gigabit network switch.
- The max distance between the switch and the local/remote unit is 328 feet (100 meters).
- Built-in video converter and switch - supports digital DVI and analog VGA.
- Connect a VGA USB computer and DVI USB computer, and switch between sources using the front panel buttons.
- Both the transmitter and receiver support VGA and DVI monitors at the same time.
- Supports USB 2.0/1.1 devices.
- Keyboard and mouse are hot-pluggable.
- Connect a mouse, keyboard, flashdrive, web camera or touchscreen display.
- Supports video wall installations up to 8x16 screens.
- Displays can be rotated 180 and 270deg .
- Bi-directional Infrared Remote (IR) control of HDMI source or display. IR transport channel can be forward or backward per the installation.
- Supports full-duplex RS232 up to 115200 baud.
- Manage transmitter/receiver connections and video wall configuration with built-in software or iOS/Android app.
- Applications using multiple transmitters and/or receivers require a managed Gigabit network switch with VLAN/IGMP and Jumbo frame support.
- When using multiple remote units, only one unit can have USB control over the source at any time.
- HDCP 1.4 compliant.
- Easily expandable - add receivers as you add control stations.
Technical details
Main features
- Power Local and remote unit: Input: 100 to 240 VAC at 50 or 60 Hz via AC adapter. Output: 5VDC, 2A
- Dimensions Local Unit WxDxH (in): 7.48x5.06x1.57 (190x129x40 mm).
- Environmental Operating temperature: 32 to 131deg F (0 to 55deg C). Storage temperature: -4 to 185deg F (-20 to 85deg C). Operating/storage relative humidity: up to 95% non-condensing RH
- Max Distance 492 feet (150 meters) in a Point-to-Point connection. 656 feet (200 meters) in a Point-to-Point or Point-to-Many connection via a network switch.
- Local Unit Host Connection Compatible with a USB computer (PC, SUN or MAC) with VGA or DVI output. Multiplatform support: Windows XP/7/10, Solaris, Linux, and MAC OS 10. One 15-pin HD connector. One female DVI-I connector. Signal type: single link digital DVI. One female USB Type B connector. One female DB9 connector for RS232 connection. Support full-duplex RS232 up to 115200 baud. Two female 3.5mm ports for connecting an IR emitter and receiver. One female 3.5mm stereo port for audio in. One female Gigabit RJ45 port for sending/receiving video, audio, USB, RS232, and IR signals. Supports HDCP 1.4. Local Access Supports a VGA and DVI monitor connected at the same time. Both monitors simultaneously display the same image. HDTV resolutions to 1080p and up to 1920x1200 (WUXGA) at 60Hz supported. One female 15-pin HD connector for local VGA monitor. One female DVI-D connector for local DVI monitor. Signal type: single link digital DVI. One female 3.5mm stereo port for audio out.
- Regulatory approvals CE, RoHS
