Moxa, EDS-G512E-4GSFP-T, 12-Port Full Gigabit Managed Ethernet Switch with 8 x 10/100/1000BaseT(X) Ports, 4 Gigabit SFP Slots, -40 to 75°C Operating Temperature
Features:
- 8 IEEE 802. 3af and IEEE 802. 3at PoE+ standard ports
- 36-watt output per PoE+ port in high-power mode
- Turbo Ring and Turbo Chain (recovery time
- RADIUS, TACACS+, MAB Authentication, SNMPv3, IEEE 802. 1X, MAC ACL, HTTPS, SSH, and sticky MAC addresses to enhance network security
- Security features based on IEC 62443
- EtherNet/IP, PROFINET, and Modbus TCP protocols supported for device management and monitoring
- Supports MXstudio for easy, visualized industrial network management
- V-ON™ ensures millisecond-level multicast data and video network recovery
Introduction
The EDS-G512E Series is equipped with 12 Gigabit Ethernet ports and up to 4 fiber-optic ports, making it ideal for upgrading an existing network to Gigabit speed or building a full Gigabit backbone. It also comes with 8-10/100/1000BaseT(X), 802. 3af (PoE), and 802. 3at (PoE+)-compliant Ethernet port options to connect high-b and width PoE devices. Gigabit transmission increases b and width for higher performance and transfers large amounts of triple-play services across a network quickly.
Redundant Ethernet technologies such as Turbo Ring, Turbo Chain, RSTP/STP, and MSTP increase the reliability of your system and improve the availability of your network backbone. The EDS-G512E Series is designed specifically for communication demanding applications, such as video and process monitoring, ITS, and DCS systems, all of which can benefit from a scalable backbone construction.
Additional Features and Benefits
- command line interface (CLI) for quickly configuring major managed functions
- Advanced PoE management function (PoE port setting, PD failure check, and PoE scheduling)
- DHCP 82 for IP address assignment with different policies
- Supports EtherNet/IP, PROFINET, and Modbus TCP protocols for device management and monitoring
- IGMP snooping and GMRP for filtering multicast traffic
- Port-based VLAN, IEEE 802. 1Q VLAN, and GVRP to ease network planning
- Supports the ABC-02-USB (Automatic Backup Configurator) for system configuration backup/restore and firmware upgrade
- Port mirroring for online debugging
For more information, please see
Data Sheet
