WLAN Interface |
WLAN Standards | - 802.11a
- 802.11i Wireless Security
|
Modulation Type | |
Frequency Band for US (20 MHz operating channels) | - 2.412 to 2.462 GHz (11 channels)
- 5.180 to 5.240 GHz (4 channels)
- 5.260 to 5.320 GHz (4 channels)(DFS (Dynamic Frequency Selection) channel support: In AP mode, when a radar signal is detected, the device will automatically switch to another channel. However according to regulations, after switching channels, a 60-second availability check period is required before starting the service.),
- 5.500 to 5.700 GHz (8 channels) excluding 5.600 to 5.640 GHz(DFS (Dynamic Frequency Selection) channel support: In AP mode, when a radar signal is detected, the device will automatically switch to another channel. However according to regulations, after switching channels, a 60-second availability check period is required before starting the service.),
- 5.745 to 5.825 GHz (5 channels)
|
Wireless Security | - WEP encryption (64-bit and 128-bit)
- WPA/WPA2-Enterprise (IEEE 802.1X/RADIUS, TKIP, AES)
- WPA/WPA2-Personal
|
Transmission Rate | - 802.11b: 1 to 11 Mbps
- 802.11a/g: 6 to 54 Mbps
- 802.11n: 6.5 to 300 Mbps
|
Transmitter Power for 802.11a | - 23±11.5 dBm at 6 to 24 Mbps
- 21±11.5 dBm at 36 Mbps
- 20±11.5 dBm at 48 Mbps
- 18±11.5 dBm at 54 Mbps
|
Transmitter Power for 802.11n (5 GHz) | - 23±11.5 dBm at MCS0/8 20 MHz
- 18±11.5 dBm at MCS7/15 20 MHz
- 23±11.5 dBm at MCS0/8 40 MHz
- 18±11.5 dBm at MCS7/15 40 MHz
|
Transmitter Power for 802.11b | - 26±11.5 dBm at 1 Mbps
- 26±11.5 dBm at 2 Mbps
- 26±11.5 dBm at 5.5 Mbps
- 25±11.5 dBm at 11 Mbps
|
Transmitter Power for 802.11g | - 23±11.5 dBm at 6 to 24 Mbps
- 22±11.5 dBm at 36 Mbps
- 20±11.5 dBm at 48 Mbps
- 19±11.5 dBm at 54 Mbps
|
Transmitter Power for 802.11n (2.4 GHz) | - 23±11.5 dBm at MCS0/8 20 MHz
- 17±11.5 dBm at MCS7/15 20 MHz
- 23±11.5 dBm at MCS0/8 40 MHz
- 17±11.5 dBm at MCS7/15 40 MHz
|
Receiver Sensitivity for 802.11a (measured at 5.680 GHz) | - Typ. -90 at 6 Mbps
- Typ. -88 at 9 Mbps
- Typ. -87 at 12 Mbps
- Typ. -85 at 18 Mbps
- Typ. -81 at 24 Mbps
- Typ. -78 at 36 Mbps
- Typ. -74 at 48 Mbps
- Typ. -73 at 54 Mbps
- Note(Due to a limitation in the receiver sensitivity performance for channels 153 and 161, it is recommended to avoid using these channels in your critical applications.),
|
Receiver Sensitivity for 802.11n (5 GHz; measured at 5.680 GHz) | - Typ. -69 dBm at MCS7 20 MHz
- Typ. -70 dBm at MCS15 20 MHz
- Typ. -64 dBm at MCS7 40 MHz
- Typ. -66 dBm at MCS15 40 MHz
- Note(Due to a limitation in the receiver sensitivity performance for channels 153 and 161, it is recommended to avoid using these channels in your critical applications.),
|
Receiver Sensitivity for 802.11b (measured at 2.437 GHz) | - Typ. -89 dBm at 1 Mbps
- Typ. -89 dBm at 2 Mbps
- Typ. -89 dBm at 5.5 Mbps
- Typ. -88 dBm at 11 Mbps
|
Receiver Sensitivity for 802.11g (measured at 2.437 GHz) | - Typ. -88 dBm at 6 Mbps
- Typ. -88 dBm at 9 Mbps
- Typ. -88 dBm at 12 Mbps
- Typ. -87 dBm at 18 Mbps
- Typ. -84 dBm at 24 Mbps
- Typ. -81 dBm at 36 Mbps
- Typ. -77 dBm at 48 Mbps
- Typ. -75 dBm at 54 Mbps
|
Receiver Sensitivity for 802.11n (2.4 GHz; measured at 2.437 GHz) | - Typ. -70 dBm at MCS7 20 MHz
- Typ. -70 dBm at MCS15 20 MHz
- Typ. -64 dBm at MCS7 40 MHz
- Typ. -65 dBm at MCS15 40 MHz
|
WLAN Operation Mode | Client, Client-Router, Slave, Sniffer |
Antenna | External, 2/2 dBi, Omni-directional |
Antenna Connectors | 2 RP-SMA female |
Ethernet Interface |
10/100BaseT(X) Ports (RJ45 Connector) | 2 |
Standards | - IEEE 802.3 for 10BaseT
- IEEE 802.3u for 100BaseT(X)
- IEEE 802.1Q for VLAN Tagging
|
Ethernet Software Features |
Management | DHCP Server/Client, HTTP, IPv4, LLDP, SMTP, SNMPv1/v2c/v3, Syslog, TCP/IP, Telnet, UDP, Proxy ARP, VLAN, Wireless Search Utility, MXview, MXview Wireless, MXconfig |
Routing | Port forwarding, Static Route, NAT |
Security | HTTPS/SSL, RADIUS, SSH |
Time Management | NTP Client, SNTP Client |
Firewall |
Filter | ICMP, MAC address, IP protocol, Port-based |
Serial Interface |
Connector | DB9 male |
Serial Standards | RS-232, RS-422/485, RS-232/422/485 |
Operation Modes | Disabled, Real COM, RFC2217, TCP Client, TCP Server, UDP |
Data Bits | 5, 6, 7, 8 |
Stop Bits | 1, 1.5, 2 |
Parity | None, Even, Odd, Space, Mark |
Flow Control | None, RTS/CTS, XON/XOFF |
Baud Rate | 75 bps to 921.6 kbps |
Serial Data Log | 256 KB |
Serial Signals |
RS-232 | TxD, RxD, RTS, CTS, DCD, GND, DTR, DSR |
RS-422 | Tx+, Tx-, Rx+, Rx-, GND |
RS-485-2w | Data+, Data-, GND |
RS-485-4w | Tx+, Tx-, Rx+, Rx-, GND |
LED Interface |
LED Indicators | SYS, LAN1, LAN2, WLAN, Serial |
Input/Output Interface |
Buttons | Reset button |
Physical Characteristics |
Housing | Metal |
IP Rating | IP30 |
Dimensions | 77.1 x 115.5 x 26 mm (3.04 x 4.55 x 1.02 in) |
Weight | 470 g (1.03 lb) |
Installation | DIN-rail mounting, Wall mounting |
Power Parameters |
Input Voltage | 9 to 30 VDC |
Power Connector | 1 removable 3-contact terminal block(s) |
Power Consumption | 11.7 W (max.) |
Reverse Polarity Protection | Supported |
Environmental Limits |
Operating Temperature | 0 to 60°C (32 to 140°F) |
Storage Temperature (package included) | -40 to 85°C (-40 to 185°F) |
Ambient Relative Humidity | 5 to 95% (non-condensing) |
Standards and Certifications |
EMC | EN 61000-6-2/-6-4, EN 55032/24 |
EMI | CISPR 22, FCC Part 15B Class A |
EMS | - IEC 61000-4-2 ESD: Contact: 8 kV
- Air: 15 kV
- IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m
- IEC 61000-4-4 EFT: Power: 2 kV
- Signal: 1 kV
- IEC 61000-4-5 Surge: Power: 2 kV
- IEC 61000-4-6 CS: 10 V
- IEC 61000-4-8 PFMF
|
Radio | EN 300 328, EN 301 489-1/17, EN 301 893, FCC ID SLE-1137C, ANATEL, MIC, NCC, SRRC, WPC, KC, RCM |
Road Vehicles | E mark E1 |
Safety | EN 60950-1, UL 60950-1 |
Vibration | IEC 60068-2-6 |
MTBF |
Time | 1,125,942 hrs |
Standards | Telcordia SR332 |
