667/S Includes Only:

Monitor
Ball Mount and Sun Hood
Two battery plates compatible with Canon LP-E6 and Sony F-970 batteries
Shoe mount adapter

Features:

7" 800 x 480 Display
3G-SDI, HDMI, YPbPr Inputs
140deg Horizontal Viewing Angle

With inputs supporting almost any camera, this 7" 3G-SDI Field Monitor from Lilliput provides an 800x480 pixel display for checking image's focus and exposure. The display's 16:9 aspect ratio fits most signals output from HD camcorders without letterboxing or pillarboxing the image, ensuring the full-screen resolution is used.

Report incorrect product information

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

All sales are final

These are made-to-order items.
This product is not eligible for return or exchange unless defective.
The average lead-time is 1 or 2 weeks.

Return and Warranty

Please note that return requests for Lilliput items must be submitted within 14 days after the delivery date.

Technical Details

Reviews

Display

Display Size

7.0" / 17.8 cm

Active Area

6 x 3.6" / 152.4 x 91.44 mm

Screen Resolution

800 x 480

Aspect Ratio

16:9

Viewing Angle

Horizontal: 140deg (70/70)
Vertical: 120deg (50/70)

Maximum Brightness

450 cd/m²

Contrast Ratio

500:1

Dot Pitch

0.0635 x 0.1905 mm

Finish

Matte

I/O

Video

1 x HDMI Type A Input
1 x 3BNC (Component) Input
1 x BNC (Composite) Input

Audio

None

Built-In Speaker

1 x 1 W

Power

1 x Barrel Input
1 x 4-Pin XLR Input

Card Slot

None

Format Support

Video Format

SDI
1080p: 50/59.94/60
1080i: 50/59.94/60
720p: 50/59.94/60
480i
576i

Power

DC Input Power

12 VDC

Battery Type

None

Power Consumption

8 W (Maximum)

Environmental

Operating Humidity

90%

Operating Temperature

-4 to 140deg F / -20 to 60deg C

Storage Temperature

-22 to 158deg F / -30 to 70deg C

General

Dimensions (W x H x D)

7.1 x 5.1 x 1.2" / 188 x 131 x 33 mm

Weight

2.7 lb / 1.2 kg

Product Details

Display

Display Size

7.0" / 17.8 cm

Active Area

6 x 3.6" / 152.4 x 91.44 mm

Screen Resolution

800 x 480

Aspect Ratio

16:9

Viewing Angle

Horizontal: 140deg (70/70)
Vertical: 120deg (50/70)

Maximum Brightness

450 cd/m²

Contrast Ratio

500:1

Dot Pitch

0.0635 x 0.1905 mm

Finish

Matte

I/O

Video

1 x HDMI Type A Input
1 x 3BNC (Component) Input
1 x BNC (Composite) Input

Audio

None

Built-In Speaker

1 x 1 W

Power

1 x Barrel Input
1 x 4-Pin XLR Input

Card Slot

None

Format Support

Video Format

SDI
1080p: 50/59.94/60
1080i: 50/59.94/60
720p: 50/59.94/60
480i
576i

Power

DC Input Power

12 VDC

Battery Type

None

Power Consumption

8 W (Maximum)

Environmental

Operating Humidity

90%

Operating Temperature

-4 to 140deg F / -20 to 60deg C

Storage Temperature

-22 to 158deg F / -30 to 70deg C

General

Dimensions (W x H x D)

7.1 x 5.1 x 1.2" / 188 x 131 x 33 mm

Weight

2.7 lb / 1.2 kg
