Buy IFM DV1330, 3-Segment 220mm Signal Light with IP 54 Protection

info@PrimeBuy.com

1-855-969-9322
1-908-282-3332 (Intl.)

Buy in Bulk 4 Applicable Promotion(s)

Buy 200 pcs, get 7% off
Save 7% each on IFM DV1330 3-Segment 220mm Signal Light with IP 54 Protection when you purchase 200 or more
Buy 100 pcs, get 5% off
Save 5% each on IFM DV1330 3-Segment 220mm Signal Light with IP 54 Protection when you purchase 100 or more
Buy 50 pcs, get 3% off
Save 3% each on IFM DV1330 3-Segment 220mm Signal Light with IP 54 Protection when you purchase 50 or more
Buy 25 pcs, get 1% off
Save 1% each on IFM DV1330 3-Segment 220mm Signal Light with IP 54 Protection when you purchase 25 or more

Quantity

Options and Related Products

Features:

Applications

For more information, please see pdf file Data Sheet

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Electrical Data
Operating Voltage [V]	18 - 30 DC; (to SELV/PELV)
Nominal Voltage DC [V]	24
Current Consumption [mA]	<200
Inputs / Outputs
Number of Inputs and Outputs	Number of Digital Inputs: 4
Inputs
Number of Digital Inputs	4
Input Current High [mA]	6
Interfaces
Communication Interface	IO-Link
Transmission Type	COM2 (38,4 kBaud)
IO-Link Revision	1.1
SDCI Standard	IEC 61131-9
SIO Mode	Yes
Required Master Port Class	A
Minimum Process Cycle Time [ms]	3.2
Operating Conditions
Ambient Temperature [°C]	-25 - 50
Storage Temperature [°C]	-40 - 75
Maximum Relative Air Humidity [%]	90
Air Pressure [kPa]	<106
Maximum Height above Sea Level [m]	2000
Protection	IP 54
Mechanical Data
Weight [g]	427.3
Dimensions [mm]	Ø 70 / L = 220
Material	Housing: ABS; lens: PC
Acoustic Signal	Buzzer
Maximum Sound Pressure [dB]	85

Electrical Data
Operating Voltage [V]	18 - 30 DC; (to SELV/PELV)
Nominal Voltage DC [V]	24
Current Consumption [mA]	<200
Inputs / Outputs
Number of Inputs and Outputs	Number of Digital Inputs: 4
Inputs
Number of Digital Inputs	4
Input Current High [mA]	6
Interfaces
Communication Interface	IO-Link
Transmission Type	COM2 (38,4 kBaud)
IO-Link Revision	1.1
SDCI Standard	IEC 61131-9
SIO Mode	Yes
Required Master Port Class	A
Minimum Process Cycle Time [ms]	3.2
Operating Conditions
Ambient Temperature [°C]	-25 - 50
Storage Temperature [°C]	-40 - 75
Maximum Relative Air Humidity [%]	90
Air Pressure [kPa]	<106
Maximum Height above Sea Level [m]	2000
Protection	IP 54
Mechanical Data
Weight [g]	427.3
Dimensions [mm]	Ø 70 / L = 220
Material	Housing: ABS; lens: PC
Acoustic Signal	Buzzer
Maximum Sound Pressure [dB]	85
