Gossen Metrawatt M194A Digital Multimeter with Analog Bar Graph
Brand New
Manufacturer warranty Description
Gossen Metrawatt, M194A, Digital Multimeter with Analog Bar Graph and Temperature Measurement
M194A Includes Only:
- 1 digital multimeter
- 1 rubber holster
- 2 batteries (1.5 V AA)
- 1 measurement cable set
- 1 condensed operating instructions
Features:
- 1000:1 clip function for optional current transformers
- Automatic blocking sockets (ABS)
- Universal use in all fields of electrical engineering!
- Measured value indication with digital display (6600 digits) and analog scale
- Measurement of voltage and current, AC and DC, resistance, temperature, continuity/diodes
- Current measurement up to 660 A via current clamp transformer with a transformation ratio of 1000:1
- Automatic measuring range selection and measured value storage
- Safety for the user and the instrument in measuring categories CAT III up to 600 V and CAT IV up to 300 V.
The METRALINE DM61 offers all of the measuring functions of a comprehensive, medium-priced multimeter: convincing technology with voltage, resistance, current and temperature measuring ranges, as well as additional measuring functions plus automatic functions such as an adjustable clip factor for current transformers.
The digital multimeter with clip function for current transformer clamps and outstanding value for the money. Time-tested Gossen Metrawatt reliability and safety. Reliable measurement results in measuring categories CAT IV 300 V and CAT III 600 V with additional safety for the user and the instrument thanks to automatic blocking sockets (ABS). The robust METRALINE DM61 digital multimeter offers a great variety of convincing performance features. It's equipped with state-of-the-art technology and it assures precision measurement results. The extremely compact and ergonomic design provides for maximized ease of use and safety. Thanks to a broad range of functions, it's universally suitable for demanding measuring tasks in a great variety of applications.
For more information, please see
Data Sheet
Technical details
- Voltage V DC: 100 μV ... 1000 V, V AC: 100 μV ... 1000 V
- Display Dual digital display with background illumination
- Resolution 6600 digits (3 6/7 place) and analog bar graph (66 points)
- Temperature -50 ... +1300°C, type K thermocouple
- Basic Accuracy 0.4% V DC
- Resistance 100 mΩ ... 66 MΩ
- Measuring Category 300 V CAT IV, 600 V CAT III
- Range Selection Automatic/manual measuring range selection
- Measurement Modes Hold / peak / min.-max. / relative (zero)
- Other functions Continuity and diode testing
- Current (direct) A DC: 10 μA ... 660 mA, A AC: 10 μA ... 660 mA
- Current with optional clamp 10 mA ... 660 A (clip: 1000:1)
- Safety feature Automatic blocking sockets (ABS)
