The 1/8 NPT Mini Super Air Nozzles provide a forceful, concentrated stream of high velocity airflow. It has fewer holes than the larger Super Air Nozzles, resulting in lower sound levels, air consumption and force. It is available in Zinc/aluminum alloy, 316 stainless steel or PEEK thermoplastic. The Mini Super Air Nozzle with Stay Set Hose and Mag Base includes EXAIR's Flexible Stay Set Hose for applications where frequent repositioning is required and a One or Two Outlet Magnetic Base for firm attachment to metallic machinery.
Applications:
- Part cleaning
- Chip removal
- Liquid blowoff
- Part cooling
- Material conveying
- Part ejection
- Fiber conveying
- Air assist
Features:
- Reduced compressed air cost
- 10 dBA average noise reduction
- Conserve compressed air
- Improved blowoff performance
- Compact
- Improved safety
- Meets OSHA noise level requirements
- Meets OSHA pressure requirements
- Improved production
EXAIR manufactures a wide selection of Air Nozzles and Jets, which are divided into two groups. The first group includes Air Nozzles and Jets that deliver force up to 22 ounces (624 grams) and are suitable for most applications. The second group includes Air Nozzles that produce high force up to 23 lbs (10,43 kg) where additional reach and force are required.
Materials:
- Type 303 Stainless Steel - high temperatures, corrosive environments. Max temp 800 ° F (426 ° C)
- Type 316 Stainless Steel - high temperatures, corrosive environments, and mechanical wear. Max temp 1000 ° F (538 ° C)
- Brass - general purpose applications. Max temp 400 ° F (204 ° C)
- Zinc aluminum alloy - general purpose applications. Max temp 250 ° F (121 ° C)
- PEEK Plastic - replaces metals in harsh environments. Offers chemical resistance and is non-marring. Max temp 320 ° F (160 ° C).
