$1,681.00 /Each
$2,739.95 You save $1,058.95 39%
Free shipping
$1,681.00 /Each
$2,739.95 You save $1,058.95 39%
Manufacturer warranty Description
Features:
- Safety Lock Nut For Mechanical Load Holding.
- Designed for use in multiple heavy lifting applications including OTR/Mining.
- Heavy Duty Aluminum Design at a fraction of the weight.
- High Flow quick connect coupler for easy connection.
- Lightweight and Compact Design makes unit highly portable.
The ESCO Professional Aluminum Locking Collar Jacks (Cylinders) are known for their quality and lightweight durable design. The most important part of lifting a heavy load is the ability to sustain the load. While most instances support jack stands are used; the Locking Collar Jack (Cylinder) acts as its own self-contained support stand. This aids in complying with OSHA regulation 29CFR1926.305
For more information, please see
Data Sheet and Manual
$1,681.00 /Each
$2,739.95 You save $1,058.95 39%
Free shipping
Technical details
Main features
- Weight 26.4 lbs. | 12 kg
- Base Plate 7 x 7 in. | 178 x 178mm
- Max Pressure 10,000 PSI
- Stroke 6 in. | 152mm
- Oil Capacity 67.07" (in)
- Lifting Capacity 50 Tons
- Min. Height 12.50 in. | 317mm
- Max. Height 18.60 in. | 472mm
- Cylinder Effective Area 10.99" (in)
- Collapsed Height (A) 12.50”
- Extended Height (B) 18.60”
- Outside Diameter (C) 5.27”
- Cylinder Width 5.27 in. | 133mm
- Piston Rod Diam. (D) Tr80x4mm
- Nut Thickness (E) 1.57 in. | 40mm
