| Enclosure Color | Black |
| Touch Technology & Capacity | PCAP (TouchPro® Projected Capacitive) - 10 Touch |
| Processor | Intel Core i5-1245UL Processor (12M Smart Cache, up to 4.40 GHz by Intel Turbo Boost Technology 2.0) with Intel vPro Support |
| Graphics | Intel Iris Xe Graphics eligible: to use the Intel Iris Xe Graphics, the system must be populated with 128-bit (dual channel) memory. Otherwise, use the Intel UHD Graphics. |
| BIOS | AMI |
| Memory (RAM) | 16GB 4800MHz DDR5 SO-DIMM on 1 of 2 slots (Expandable to 64GB maximum on 2 slots) |
| Storage | 256GB M.2 PCIe (NVMe) SSD 160 TBW |
| TPM | 2.0 |
| Active Management Technology (AMT) | Intel Active Management Technology |
| Diagonal Size | 21.5" diagonal, Active matrix TFT LCD (LED) |
| Aspect Ratio | 16:9 |
| Active Area | 18.74" x 10.54" / 476.1 mm x 267.8 mm |
| Resolution | 1920 x 1080 at 60Hz |
| Number of Colors | 16.7 million |
| Brightness (typical) | - LCD panel: 250 nits
- TouchPro PCAP: 212.5 nits
|
| Response Time-total (typical) | 14 msec |
| Contrast Ratio | 1000:1 |
| Viewing Angle | Horizontal: ±89° or 178° total / Vertical: ±89° or 178° total |
| I/O Ports | - 1x RJ45 LAN (Gigabit) Port
- 4x USB 3.0 Ports
- 4x Micro USB 2.0 Ports for Elo Edge Connect peripherals
- 1x 24V Powered USB Port
- 2x 12V Powered USB Ports
- 1x RJ50 Powered Serial Port
- 1x 12V/24V Cash Drawer Port (EPSON Pinout, 24V default; selectable by BIOS setting)
- 1x Full-function USB-C Port (Power up to 27W, USB 3.0, Display Port, Additional Video Out)
- 1x Audio Port (3.5 mm headset jack)
|
| Wireless | 802.11 a/b/g/n/ac/ax 2.4GHz, 5GHz and 6GHz |
| Bluetooth | Bluetooth 5.3 |
| Speakers | 2 x 2W internal speakers |
| OS | Windows 10 IoT Enterprise LTSC 64-bit |
| Languages | Windows 10 - 36 Language groups |
| Power Supply | - External 24VDC universal-type power supply brick
- AC input voltage: 100-240 VAC
- Input frequency: 50-60 Hz
- Maximum output power: 180W
|
| Power Consumption (Typical) | - Without Peripherals*
- On i5: 57W
- Sleep: < 5W
- Off: < 0.5W
- *Condition for i5 and i7 models with 16GB DIMM/256GB SSD, others with 8GB DIMM/128GB SSD
|
| Dimensions | With stand: 20.70" x 14.52" x 8.06" / 525.8 mm x 368.7 mm x 204.6 mm |
| Weight (Unpackaged) | With stand: 22.09 lbs / 10.02 kg |
| Operating Temperature | - 0°C to 35°C / 32°F to 95°F
- Note: the thermal report pass airflow 0.5m/s condition. For non-OS SKUs, recommend using the Elo optimize TDP tool for better performance.
|
| Storage Temperature | -20°C to 60°C / -4°F to 140°F |
| Humidity | - Operating: 20% to 80%
- Storage: 5% to 95% (38.7°C max wet bulb temperature)
|
