Comnet FVR110S1 Digital Video Receiver Data Transceiver Singlemode

Features:

• Supports Panasonic Proteus, Pelco Coaxitron and Bosch Bilinx Up-the-Coax systems
• 1 Full Duplex Data channel
• 1 Full Duplex Contact Closure
• Distances up to 30 miles (48 km)
• Exceeds all requirements for RS-250C short-haul transmission: True broadcast video performance
• Time-Based Corrected Up-the-Coax Data
• Compatible with all NTSC, PAL, or SECAM CCTV camera systems
• Designed to meet full compliance with the environmental requirements (ambient operating temperature, mechanical shock, vibration, humidity with condensation, high-line/low-line voltage conditions and transient voltage protection) of NEMA TS-1/TS-2 and the Caltrans Specification for Traffic Signal Control Equipment
• Voltage transient protection on all power and signal input/output lines provides protection from power surges and other voltage transient events
• Automatic resettable fuses on all power lines
• Bi-color (Red/Green) LED status indicators provide rapid indication of critical operating parameters
• FVT/FVR110(M,S)1 is a hot-swappable rack module
• FVT/FVR110(M,S)1 is interchangeable between stand-alone or rack mount use - ComFit

Applications:

• High-Performance CCTV with PTZ Control

The ComNet FVT/FVR110 series is a video transmitter/receiver and data transceiver that supports the simultaneous transmission of short haul quality 10-bit EIA RS-250C digitally encoded video and bi-directional data over one multimode or single mode optical fiber. The module is universally compatible with major CCTV camera manufacturers and supports RS232, RS422 and 2 or 4-wire RS485 data interfaces and most data protocols. It also supports "up-the-coax" data transmission from all major manufacturers, utilizing time-base correction these units can achieve distances of 48km. The FVT/FVR110 supports Panasonic Proteus, Pelco Coaxitron and Bosch Bilinx Up-the-Coax systems. The FVT110 also transmits a single bi-directional contact closure signal. Packaged in the exclusive ComNet ComFit housing, the full-size units may be either wall or rack-mounted, or may be DIN-rail mounted by the addition of ComNet model DINBKT1 adaptor plate.
