BZBGEAR BG-CAP-HA USB 3.0 Powered HDMI Capture Device
Brand NewNotification
Please review our Return Policy.
Manufacturer warranty Description
BG-CAP-HA Includes Only:
- 1x BG-CAP-HA USB 3.0 Powered HDMI Capture Device
- 1x User Manual
Features:
- 1080P at60Hz Resolution - Capture and store Full HD video on your device
- Audio Input - Embeds audio from a microphone or other device
- Audio Output - De-Embeds audio from HDMI for analog devices
The BG-CAP-HA is a 4K capture device designed to convert an HDMI source to a USB 3.0 output for recording, editing, and/or streaming from a PC or Mac. This unit receives audio and video at resolutions up to 4K at60Hz 4:4:4 HDR10 with an output resolution of 1080P at60Hz.
Either it is live video streaming setup for the interview, or streaming of gaming process with voice over, or conference room setup with camera and microphone - this device will do the job.
Featuring an HDMI loop-out for a local display, it is also equipped with 3.5mm audio input and output ports that provide audio embedding or de-embedding for connecting microphone or external audio system.
The USB 3.0 cable also supplies power to the unit, eliminating the need for a power supply.
The BG-CAP-HA is HDCP compliant and will not capture protected content.
Technical details
- Input (1) HDMI In, (1) Audio In
- Output (1) HDMI Out, (1) USB, (1) Audio Out
- Relative Humidity 10% to 90%, non-condensing
- Storage Temperature -13° to +158°F / -25° to +70°C
- Net Weight 0.17 lbs [75g]
- Output Connector (1) Type-A HDMI, (1) Type-A USB, (1) 3.5mm jack
- Operation Temperature +23° to +131°F / -5° to +55°C
- Input Connector (1) Type-A HDMI, (1) 3.5mm jack
- OS Support Windows, Mac OS X, Linux
- Dimension (W*H*D) 102 x 13 x 61mm
- HDMI Input Resolution Up to 4K at60Hz 4:4:4, HDR10
- HDMI Output Resolution Up to 4K at60Hz 4:4:4, HDR10
- HDMI Standard 2.0
- HDMI Audio Format LPCM 7.1 audio, Dolby Atmos®, Dolby® TrueHD, Dolby Digital® Plus, DTS:X™, and DTS-HD® Master Audio™ pass-through
- USB Output Color Space YUV2, RGB
- Microphone Audio Format PCM 2.0
- Headphone Audio Format PCM 2.0
- Compatible Media Player OBS, PotPlayer, VLC and so on
