| Network Video Recorder |
| Video |
| IP Video-Input | 4 Channels IPC |
| Output | - HDMI1: 3840 x 2160 / 1920 x 1080 / 1280 x 1024
- VGA x 1: 1920 x 1080 / 1280 x 1024
|
| IP Video-Input Resolution | 8MP / 5MP / 4MP / 3MP / 1080P / 960P / 720P at 25fps and 30fps |
| Incoming Bandwidth (Mbps) | 40Mbps |
| Outgoing Bandwidth (Mbps) | 40Mbps |
| Video Compression | Standard H.265 |
| Audio |
| Network Input | 4 Channel IPC Audio Input |
| Local Output | RCA x 1 |
| 2-Way Audio | RCA x 1 |
| HDMI Audio Output | Yes |
| Compression | G.711 (U/A) |
| Recording |
| Resolution | 8MP / 5MP / 4MP / 3MP / 1080P / 960P / 720P |
| Record Stream | Dual Stream Recording |
| Mode | Manual, Timer, Motion, Sensor |
| Playback |
| Smart Search | Recorded Events are Color-Coded to Reflect the Specific Type of Event that was Recorded (Scheduled, Motion, Alarm, Etc.) |
| Search | Time slice / Time / Event / Tag Search |
| Function | Play, Pause, Fast Forward, Fast Rewind, Digital Zoom, etc. |
| Simultaneous Playback | Max 4 Channels |
| Alarm |
| Alarm Input | IPC Alarm Input Supported |
| Alarm Output | IPC Alarm Input Supported |
| Mode | Manual, Sensor, Motion, Exception |
| Alarm Trigger | Record, Snap, Preset, E-mail, etc. |
| Storage |
| HDD Interface | SATA x 1, Max 18T per HDD |
| Backup |
| Network Backup | Yes |
| Local Backup | USB Flash Drive, USB Mobile HDD |
| Network |
| Interface | RJ45 10 / 100 / 1, 000 Mbps x 1 |
| PoE Port | RJ45 x 4 |
| Protocol | TCP/ IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP |
| Web Client | Max. 10 Online Users |
| External Interface |
| Remote Controller | Optional |
| USB | USB 2.0 x 1 (Front Panel), USB 2.0 x 1 (Rear Panel) |
| General |
| Power Supply | DC 48V |
| Power Consumption | ≤5W (Without HDD) |
| Working Environment | 14°~122°F (-10°~50° Celcius) |
| Working Humidity | 10% ~ 90% (Non-Condensing) |
| Dimensions | 11.61" x 1.65" x 9.69" (295 mm x 42 mm x 246 mm) |
| Fixed Eyeball Network Camera |
| Camera |
| Image Sensor | 1/2.8" Progressive Scan Cmos |
| Resolution | 8MP |
| Image Size | 3840 x 2160 |
| Min. Illumination | Color: 0.05 Lux at F1.2 (AGC ON) BW: 0 Lux w IR ON |
| Shutter Speed | 1/20, 000s ~ 1/5s |
| Slow Shutter | Supported |
| IR Distance | Up to 98ft. (30m) |
| Lens | Fixed 2.8 mm (M12) |
| Field of View | Horizontal: 107°, Vertical: 57°, Diagonal: 128° |
| WDR | 120dB |
| Video Stream |
| Max. Image Resolution | 3840 x 2160 at 30fps |
| Supported Resolutions | 3840 x 2160, 3072 x 1728, 2592 x 1944, 2592 x 1520, 2304 x 1296, 1920 x 1080, 1280 x 720, 640 x 480, 320 x 240 |
| Main Stream | 3840 x 2160, 3072 x 1728, 2592 x 1944, 2592 x 1520, 2304 x 1296, 1920 x 1080, 1280 x 960, 1280 x 720 |
| Sub Stream | 720P (1280x720), VGA (640x480), QVGA (320x240) |
| Mobile Stream | VGA (640x480), QVGA (320x240) |
| Video Compression | H.265 / H.264 |
| Video Bit Rate | 8 Kbps ~ 16 Mbps (CBR / VBR Adjustable) |
| Max. Framerate | 50Hz: 25fps at 8MP / 5MP / 4MP / 3MP / 2MP / 960P / 720P / VGA / QVGA, 60Hz: 30fps at 8MP / 5MP / 4MP / 3MP / 2MP / 960P / 720P / VGA / QVGA |
| Network |
| Ethernet | 1 x RJ45 10M / 100M (BASE-T) |
| ONVIF | ONVIF (Profile S/G/T, 20.06) |
| Protocol | HTTP, HTTPs, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP/IP, PPPoE, DHCP |
| Security | IP Address Filter; Complicated Password; Authenticated Username and Password |
| Image |
| Day and Night | IR cut filter with auto switch (Day / Night / Auto / Schedule) |
| True WDR | Yes |
| Digital NR | Yes (3D DNR) |
| Backlight Compensation (BLC) | Off / On (5 Zone) |
| Motion Detection | Off / On (8 Level) |
| Gain Control | Auto |
| White Balance | Auto/Manual |
| Privacy Mask | Off / On (4 Zone, Rectangle) |
| Flip / Mirror | Flip/Corridor/Rotation |
| Sharpness | Yes |
| Image Setting | Yes |
| Language | Support for English and Korean |
| Video ANALYTICS |
| Supported Recorders | Diversity Series |
| On-Board Storage | Micro SD slot, up to 256GB |
| Alarm/Audio | No / Built-in Microphone |
| Hardware Reset | Yes |
| Smart Feature | PID, LCD, PD/VD, FD |
| Smart Events | Human Detection, Face Detection, Vehicle Detection |
| Alarm Link Events | Motion Detection |
| General |
| Angle Adjustment | Any Angle |
| Input Voltage | DC 12V / PoE (802.3af) |
| Power Consumption | ≤6W |
| Ingress Protection | IP67 |
| Working Temperature | -22°~131° F (-30°~55° C) |
| Dimensions | 3.92" x 3.32" (100.5 mm x 85.2 mm) |
