Buy AVYCON AVC-NAE41F28, Diversity Series 4 MP Bullet Network Camera

info@PrimeBuy.com

1-855-969-9322
1-908-282-3332 (Intl.)

Options and Related Products

Resolution:: Resolution: 4 MP

AVYCON, AVC-NAE41F28, Diversity Series 4 MP Smart Defender Infinitecolor Bullet Network Camera

Features:

4MP (2560x1440) @25fps H.265 / H.264
Full Color Smart Defender Camera
2.8mm Fixed Lens (F1.0)
3D DNR, D-WDR
White Light LED / Strobe (Blue & Red) Light
Built-in MIC / Speaker
Built-in Micro SD card slot (up to 512GB)
AI Features: Intrusion Detection, Tripwire Counting, Loitering Detection, Region Entrance / Exiting Detection
IP67 Ingress Protection
PoE / DC12V Power Supply
Support Remote Monitoring via AVYCON ONE (Mobile App) and AVYCON CMSONE (CMS)

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

Imaging Device

1/3"

Effective Pixels

4MP 2560(H) × 1440(V)

Scanning System

Progressive CMOS

Min. Illumination

Color 0.002 Lux @ F1.0, AGC ON; B/W 0 lux @ IR ON

Lens Type

Fixed (M12)

Focal Length (Zoom Ratio)

2.8 mm Fixed

Max. Aperture Ratio

F No. 1.0

Angular Field of View

Horizontal: 95°
Vertical: 51°
Diagonal: 112°

Min. Object Distance

6.56 ft (2 m)

IR LED

White Light

Red Blue Light

2 (1 Red & 1 Blue)

IR Viewable Length

Up to 82 ft (25 m)

White Light Viewable Length

Up to 65 ft (20 m)

Type of Complementary Light

Default white light, switchable infrared light

Motion Detection

Smart Motion Detection

Pedestrian Detection
Vehicle Detection

Wide Dynamic Range

DWDR

Digital Noise Reduction

3D DNR

Day & Night

Full Color (default) / Day & Night / Smart Illumination

White Balance

Auto / Manual

Electronic Shutter Speed

1/5 ~ 1/20000s

Edge Storage

Micro SD/SDHC/SDXC Slot (up to 512GB)

Alarm Event

Warning Light
Siren
E-mail Notification
Event Push
Micro SD recording

Audio I/O

Built-in MIC
Built-in Speaker

Hardware Reset

Yes

Smart Feature

Intrusion Detection (ID)
Tripwire Counting (TC)
Loitering Detection (LD)
Region Entrance / Exiting Detection

Ethernet

RJ45 (10/100BASE-T)

Video Compression Format

H.265 / H.264

Resolution

Main Stream @25fps: 4MP (2560x1440)
Sub Stream @25fps: VGA (640x480)

Video Quality Adjustment

512Kbps ~ 4Mbps

Bitrate Control Method

CBR / VBR

IPv4

Protocol

TCP/IP
HTTP
DHCP
DNS
DDNS
RTP/RTSP
SMTP
NTP
HTTPS

Application Programming Interface

ONVIF, REST API

Web Viewer

IE10, IE11

Operating Conditions

-31~140°F (-35~+60°C) / ≤ 90% RH

Ingress Protection

IP67

Input Voltage / Current

DC12V / PoE (IEEE802.3af)

Power Consumption

DC12V: max 7W; PoE (48V): max 8.3W

Material

Metal

Dimensions (H x W x D)

3.96 x 3.46 in (100.5 x 87.9 mm)

Weight

0.68 lb (312 g)

Product Details

Imaging Device

1/3"

Effective Pixels

4MP 2560(H) × 1440(V)

Scanning System

Progressive CMOS

Min. Illumination

Color 0.002 Lux @ F1.0, AGC ON; B/W 0 lux @ IR ON

Lens Type

Fixed (M12)

Focal Length (Zoom Ratio)

2.8 mm Fixed

Max. Aperture Ratio

F No. 1.0

Angular Field of View

Horizontal: 95°
Vertical: 51°
Diagonal: 112°

Min. Object Distance

6.56 ft (2 m)

IR LED

White Light

Red Blue Light

2 (1 Red & 1 Blue)

IR Viewable Length

Up to 82 ft (25 m)

White Light Viewable Length

Up to 65 ft (20 m)

Type of Complementary Light

Default white light, switchable infrared light

Motion Detection

Smart Motion Detection

Pedestrian Detection
Vehicle Detection

Wide Dynamic Range

DWDR

Digital Noise Reduction

3D DNR

Day & Night

Full Color (default) / Day & Night / Smart Illumination

White Balance

Auto / Manual

Electronic Shutter Speed

1/5 ~ 1/20000s

Edge Storage

Micro SD/SDHC/SDXC Slot (up to 512GB)

Alarm Event

Warning Light
Siren
E-mail Notification
Event Push
Micro SD recording

Audio I/O

Built-in MIC
Built-in Speaker

Hardware Reset

Yes

Smart Feature

Intrusion Detection (ID)
Tripwire Counting (TC)
Loitering Detection (LD)
Region Entrance / Exiting Detection

Ethernet

RJ45 (10/100BASE-T)

Video Compression Format

H.265 / H.264

Resolution

Main Stream @25fps: 4MP (2560x1440)
Sub Stream @25fps: VGA (640x480)

Video Quality Adjustment

512Kbps ~ 4Mbps

Bitrate Control Method

CBR / VBR

IPv4

Protocol

TCP/IP
HTTP
DHCP
DNS
DDNS
RTP/RTSP
SMTP
NTP
HTTPS

Application Programming Interface

ONVIF, REST API

Web Viewer

IE10, IE11

Operating Conditions

-31~140°F (-35~+60°C) / ≤ 90% RH

Ingress Protection

IP67

Input Voltage / Current

DC12V / PoE (IEEE802.3af)

Power Consumption

DC12V: max 7W; PoE (48V): max 8.3W

Material

Metal

Dimensions (H x W x D)

3.96 x 3.46 in (100.5 x 87.9 mm)

Weight

0.68 lb (312 g)

Note

Note: Please read description carefully. Do not base your order on the picture presented.
