Automatic Timing & Controls Diversified, TDL-120-AKA-900, Knob Adjustable Flasher Relay Output w/ 9 - 900 Seconds Timing

Features:

When power is applied to the input, the OFF time begins.
Upon completion of the OFF time, the relay energizes and the ON time begins.
Upon completion of the ON time, the relay de-energizes and one cycle is complete.
This OFF/ON cycling continues until the voltage is removed from the input.
The off time always equals the on time.
Panel Mount Bracket A (100054330) can/should be used for the Style A Housing

For more information, please see pdf file Data Sheet

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

Timing Ranges

9 - 900 Seconds Timing

Output Rating

DPDT, 10 A at 250VAC or 24VDC, resistive;
211 VA at 120VAC, inductive

Timing Tolerances

Minimum Setting +0-20%
Maximum Setting ±10%

Repeatability

1% maximum; no first cycle effect

Reset Times

Before Time Out 100 mSEC
After Time Out 50 mSEC

Recycle Time

40 mSEC

Supply Voltage

120VAC or VDC, 50/60 Hz; ±10%

False Transfer

Reverse Polarity Protected

Yes

Power Consumption

3 watts (approximately)

Duty Cycle

Continuous

Temperature Rating

Operate 32° to 131°F (0° to +55°C)
Storage -49° to 185°F (-45° to +85°C)

Life Expectancy

Mechanical 10 million operations (minimum)
Electrical 100,000 operations at rated load

Enclosure Style

8-Pin or 11-pin Round Plug-in

Weight

6.4 oz

Type of Operation

Knob Adjustable

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Product Details

Timing Ranges

9 - 900 Seconds Timing

Output Rating

DPDT, 10 A at 250VAC or 24VDC, resistive;
211 VA at 120VAC, inductive

Timing Tolerances

Minimum Setting +0-20%
Maximum Setting ±10%

Repeatability

1% maximum; no first cycle effect

Reset Times

Before Time Out 100 mSEC
After Time Out 50 mSEC

Recycle Time

40 mSEC

Supply Voltage

120VAC or VDC, 50/60 Hz; ±10%

False Transfer

Reverse Polarity Protected

Yes

Power Consumption

3 watts (approximately)

Duty Cycle

Continuous

Temperature Rating

Operate 32° to 131°F (0° to +55°C)
Storage -49° to 185°F (-45° to +85°C)

Life Expectancy

Mechanical 10 million operations (minimum)
Electrical 100,000 operations at rated load

Enclosure Style

8-Pin or 11-pin Round Plug-in

Weight

6.4 oz

Type of Operation

Knob Adjustable

Note

Note: Please read description carefully. Do not base your order on the picture presented.
