Buy AIDA Imaging CS-8.0F, 8mm Fixed Focal 5 Mega-Pixel Lens

info@PrimeBuy.com

1-855-969-9322
1-908-282-3332 (Intl.)

Features:

Optimized and tuned with HD Cameras.
Compatible with 1.3 to 5MP Cameras.
CS-Mount.
1/2.5' Optical Format.
Fixed Iris Range.
HFOV: 45° on 1/2.5' sensors, 36.6° on 1/3' image sensors.

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

Back Focal Length

7.7 mm

Focal Length

8 mm

F-Stop

F2.0

Focus Operation

Manual

FOV

1/2.5" : HFOV 45°
1/3" : HFOV 36.6°

Image Format Max

1/2.5" Sensor

Mid Megapixel Count

TV Distortion

-18.5% with 1/2.5" Sensor

Mount Type

CS-Mount

Operation Temperature

-20°C - 60°C

Dimension

31.2 mm x 28 mm / 1.81" x 1.39"

Weight

2 g / 0.0004 lbs

Product Details

Back Focal Length

7.7 mm

Focal Length

8 mm

F-Stop

F2.0

Focus Operation

Manual

FOV

1/2.5" : HFOV 45°
1/3" : HFOV 36.6°

Image Format Max

1/2.5" Sensor

Mid Megapixel Count

TV Distortion

-18.5% with 1/2.5" Sensor

Mount Type

CS-Mount

Operation Temperature

-20°C - 60°C

Dimension

31.2 mm x 28 mm / 1.81" x 1.39"

Weight

2 g / 0.0004 lbs

Note

Note: Please read description carefully. Do not base your order on the picture presented.
