| Camera |
| Sensor | 1/2.8", 2.0 megapixel, progressive scan, CMOS |
| Minimum Illumination | Colour: 0.001Lux (F1.6, AGC ON) 0 lux with IR on |
| Day/Night | IR-cut filter with auto switch (ICR) |
| Adjustment angle | - Pan: 0°~355°
- Tilt: 0°~70°
- Rotate: 0°~355°
|
| Shutter | Auto/Manual, 1 ~ 1/100000s |
| S/N | >52 dB |
| WDR | 120dB |
| Lens |
| Lens type | 2.8~12mm at F1.4, AF automatic focusing and motorized zoom lens |
| Iris | P-iris |
| Field of View (H) | 100.3°~32° |
| Field of View (V) | 54°~18.3° |
| Field of View (D) | 130.4°~39.4° |
| DORI Distance |
| Lens (mm) | |
| Detect (m) | - 43.4(142.5ft)
- 186.2(610.9ft)
|
| Observe (m) | - 17.4(57.0ft)
- 74.5(244.4ft)
|
| Recognize (m) | |
| Identify (m) | |
| Illuminator |
| IR Range | Up to 40m (131ft) IR range |
| Wavelength | 850nm |
| IR On/Off Control | Auto/Manual |
| Video |
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| Frame Rate | - Main Stream: 1080P (1920*1080),Max 60fps;
- Sub Stream: 1080P (1920*1080), Max 60fps;
- Third Stream: D1 (720*576), Max 60fps
|
| Video Bit Rate | 128 Kbps~16 Mbps |
| OSD | Up to 8 OSDs |
| Privacy Mask | Up to 4 areas per scene |
| ROI | Up to 8 areas |
| Video Stream | Triple streams |
| Image |
| White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
| Digital noise reduction | 2D/3D DNR |
| Smart IR | Support |
| Flip | Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise |
| BLC | Support |
| HLC | Support |
| Defog | Digital Defog |
| Intelligent |
| Smart intrusion prevention | Support false alarm filtering: Cross Line detection, Intrusion detection, Enter Area detection, Leave Area detection |
| Statistical Analysis | People counting, support people flow counting and crowd density monitoring |
| Attribute Collection | SIP with color retrieval |
| Events |
| Basic Detection | Motion detection, Audio detection, Tampering alarm |
| General Function | Watermark, IP Address Filtering, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication |
| Audio |
| Audio Compression | G.711U, G.711A |
| Audio Bitrate | 64 Kbps,128kbps |
| Two-way Audio | Support |
| Suppression | Support |
| Sampling Rate | 8KHz,16KHz |
| Storage |
| Edge Storage | Micro SD, up to 256 GB |
| Network Storage | ANR, NAS (NFS) |
| Network |
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP, SSL/TLS |
| Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API, SDK |
| User/Host | Up to 32 users. 3 user levels: administrator, common user and operator |
| Security | Password protection, Strong password, HTTPS encryption, Export operation logs, Basic and digest authentication for RTSP, Digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF |
| Client | |
| Web Browser | Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above |
| Interface |
| Audio I/O | 1/1 |
| Alarm I/O | 2/1 |
| Built-in Mic | Support |
| Network | 1 * RJ45 10M/100M Base-TX Ethernet |
| Certification |
| EMC | - CE-EMC (EN 55032: 2015+A1:2020,EN 61000-3-3: 2013+A1: 2019,EN IEC 61000-3-2: 2019+A1: 2021,EN 55035: 2017+A11:2020)
- FCC (FCC CFR 47 part15 B, ANSI C63.4-2014)
|
| Safety | - CE LVD (EN 62368-1:2014+A11:2017)
- CB (IEC 62368-1:2014)
- UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01)
|
| Environment | CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Protection | - IP67 (IEC 60529:1989+AMD1:1999+AMD2:2013)
- IK10 (IEC 62262:2002)
|
| General |
| Power | - DC 12Vplusmn;25%, PoE (IEEE 802.3af)
- Power consumption: Max 8W
|
| Power Interface | Ø 5.5mm coaxial power plug |
| Dimensions (Ø x H) | Φ148.0 x 111.4mm (Φ5.8” x 4.4”) |
| Weight | 0.93kg(2.16lb) |
| Material | Metal |
| Working Environment | -30°C ~ +60°C (-22°F ~ 140°F), Humidity:≤95% RH(non-condensing) |
| Strorage Environment | -30°C ~ +60°C (-22°F ~ 140°F), Humidity:≤95% RH(non-condensing) |
| Surge Protection | 6KV |
| Reset Button | Support |
 |
