Options and Related Products

Cord Type:: Cord Type: Straight

Features:

180cm (6ft) coverage radius
Piezoelectric type
Memory reset function

Diagram

For more information, please see pdf file Data Sheet

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Detection System	Piezoelectric type
Alarm Output
Dry contact relay output	N/C
Reset time	approx. 2sec
Voltage	30V (AC/DC) 0.5A Max
Supply Voltage	10.5 to 15V DC (non-polarity)
Current Consumption	20mA
Features	Memory reset
Ambient Temperature	-30°C to +55°C (-22°F to +131°F)
Mounting Position	Surface of glass (indoor)
External Dimensions	37.0 dia x 15mm (1.46 dia x 0.6”)
Weight	30g (1.06oz)

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Product Details

Detection System	Piezoelectric type
Alarm Output
Dry contact relay output	N/C
Reset time	approx. 2sec
Voltage	30V (AC/DC) 0.5A Max
Supply Voltage	10.5 to 15V DC (non-polarity)
Current Consumption	20mA
Features	Memory reset
Ambient Temperature	-30°C to +55°C (-22°F to +131°F)
Mounting Position	Surface of glass (indoor)
External Dimensions	37.0 dia x 15mm (1.46 dia x 0.6”)
Weight	30g (1.06oz)

Note: Please read description carefully. Do not base your order on the picture presented.
