PureLink, HCE III-L TX/RX, 4K HDMI over HDBaseT Extension System with Loop Out

Features:

Supports resolutions up to 4K at60Hz (4:4:4)
Supports data rates up to 18 Gbps
HDCP 2.2/ HDCP 1.4 Compliant
Transmits Ultra HD/4K signals up to 130 ft. (40m)
Supports HDR10 and Full 3D
HDMI loop-out on transmitter and additional HDMI output on receiver
Bi-directional IR and RS-232 extension
Bi-directional PoC (Rx powered by Tx or Tx powered by Rx)
EDID selector (auto, local, remote)

The HCE III-L Tx/Rx is a premium HDMI 2.0 HDBaseT™ Extension System for Ultra HD/4K and HDR formats featuring an HDMI loop out on the transmitter for preview monitoring, as well as an additional output on the receiver for local distribution. The HCE III-L Tx/Rx supports 4K at60Hz with 4:4:4 chroma sampling, as well as HDMI data rates up to 18 Gbps with HDCP 2.2 compliance. The HCE III can transmit Ultra HD/4K signals to distances up to 130 feet (40 meters) and 1080p to distances up to 230 ft. (70 meters) over a single category cable with embedded multi-channel audio, CEC pass-through, bi-directional RS-232 and IR control, and PoC.

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

Performance
Supported Distance	Ultra HD/4K up to 130ft. (40m), 1080p up to 230 ft. (70m)
Supported Resolutions	4K at60Hz (4:4:4), 1080p, 1080i, 720p(50Hz), 576p, 480p, 576i, 480i
Compliance	HDMI 2.0, HDCP 2.2, HDCP 1.4
Video Bandwidth	up to 18 Gbps
RS-232	(1) RS-232 [3-pin phoenix]
IR Extension	(1) x IR input [3.5mm stereo mini-jack]; 1 x IR output [3.5mm stereo mini-jack]
Power Supply	DC 24V/1A
Operating Temperature	32° ~ 117° F (0° to 47° C)
Storage Temperature	- 40° ~ 158° F (-40° to 70° C)
Relative Humidity	0 ~ 90% non-condensing
MTBF	50,000 hours
Rack Mounting Option	Standard 19 inch rack-mountable design
Enclosure
Rack Mounting Option	Standard 19 inch rack-mountable design
Product Dimensions	5.5" x 2.6" x 0.8" (139.4 mm x 66.8 mm x 20 mm)
Product Weight	1.19 lbs. (0.54 kg)
PRODUCT DIMENSIONS	12.21 x 7.09 x 2.76 in. (310 x 180 x 70 mm)
Product Weight	7.7 lbs (3.5 kg)

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Product Details

Performance
Supported Distance	Ultra HD/4K up to 130ft. (40m), 1080p up to 230 ft. (70m)
Supported Resolutions	4K at60Hz (4:4:4), 1080p, 1080i, 720p(50Hz), 576p, 480p, 576i, 480i
Compliance	HDMI 2.0, HDCP 2.2, HDCP 1.4
Video Bandwidth	up to 18 Gbps
RS-232	(1) RS-232 [3-pin phoenix]
IR Extension	(1) x IR input [3.5mm stereo mini-jack]; 1 x IR output [3.5mm stereo mini-jack]
Power Supply	DC 24V/1A
Operating Temperature	32° ~ 117° F (0° to 47° C)
Storage Temperature	- 40° ~ 158° F (-40° to 70° C)
Relative Humidity	0 ~ 90% non-condensing
MTBF	50,000 hours
Rack Mounting Option	Standard 19 inch rack-mountable design
Enclosure
Rack Mounting Option	Standard 19 inch rack-mountable design
Product Dimensions	5.5" x 2.6" x 0.8" (139.4 mm x 66.8 mm x 20 mm)
Product Weight	1.19 lbs. (0.54 kg)
PRODUCT DIMENSIONS	12.21 x 7.09 x 2.76 in. (310 x 180 x 70 mm)
Product Weight	7.7 lbs (3.5 kg)

Note

Note: Please read description carefully. Do not base your order on the picture presented.
