Buy Pelco E1-CMG-SVR-P, VideoXpert Enterprise Core and Gateway Server

info@PrimeBuy.com

1-855-969-9322
1-908-282-3332 (Intl.)

Features

The core is the heart of the system, it maintains the database of cameras and recording devices. While the media gateway serves as the video traffic monitor to route video traffic to appropriate users as requested. Although available as separate components, they can be combined to serve as a single server for multiple cameras.

See more product information See less

Return and Warranty

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

Device Type

Video surveillance appliance

Height (Rack Units)

Width

17.1 in

Depth

20 in

Height

3.5 in

Weight

28.79 lbs

Enclosure Color

Dark gray

Localization

United Kingdom, United States, Europe

Processors Installed

1 x Intel Xeon E3-1275V3 3.5 GHz

Max Supported Qty

RAM

32 GB (32 GB max) DDR3 SDRAM

Hard Drive

SSD 480 GB x 1

Hard Drive (2nd)

HDD - 1 TB x 1

Form Factor

Rack-mountable

Connectivity Technology

Wired

Data Link Protocol

Ethernet, Fast Ethernet, Gigabit Ethernet

Status Indicators

HDD activity, status, Internet

Features

4K resolution support, ONVIF support

Compliant Standards

UPnP

Interfaces

3 x USB 2.0
2 x USB 3.0
2 x DisplayPort output
1 x DVI-D output
1 x VGA output
2 x 1000Base-T

Included Accessories

USB flash drive, keyboard, mouse, rack mount kit

Compliant Standards

UL, C-Tick, ISO 9001, cUL, CCC, ICES-003 Class A, FCC Part 15 A, KC, ISO/IEC 14496/10

Pricing Type

Enterprise

Power Device

Internal power supply

Voltage Required

AC 120/230 V (50/60 Hz)

Power Consumption Operational

160 Watt

OS Provided

Microsoft Windows Server 2012

Min Operating Temperature

50 °F

Max Operating Temperature

95 °F

Humidity Range Operating

20 - 80% (non-condensing)

Product Details

Device Type

Video surveillance appliance

Height (Rack Units)

Width

17.1 in

Depth

20 in

Height

3.5 in

Weight

28.79 lbs

Enclosure Color

Dark gray

Localization

United Kingdom, United States, Europe

Processors Installed

1 x Intel Xeon E3-1275V3 3.5 GHz

Max Supported Qty

RAM

32 GB (32 GB max) DDR3 SDRAM

Hard Drive

SSD 480 GB x 1

Hard Drive (2nd)

HDD - 1 TB x 1

Form Factor

Rack-mountable

Connectivity Technology

Wired

Data Link Protocol

Ethernet, Fast Ethernet, Gigabit Ethernet

Status Indicators

HDD activity, status, Internet

Features

4K resolution support, ONVIF support

Compliant Standards

UPnP

Interfaces

3 x USB 2.0
2 x USB 3.0
2 x DisplayPort output
1 x DVI-D output
1 x VGA output
2 x 1000Base-T

Included Accessories

USB flash drive, keyboard, mouse, rack mount kit

Compliant Standards

UL, C-Tick, ISO 9001, cUL, CCC, ICES-003 Class A, FCC Part 15 A, KC, ISO/IEC 14496/10

Pricing Type

Enterprise

Power Device

Internal power supply

Voltage Required

AC 120/230 V (50/60 Hz)

Power Consumption Operational

160 Watt

OS Provided

Microsoft Windows Server 2012

Min Operating Temperature

50 °F

Max Operating Temperature

95 °F

Humidity Range Operating

20 - 80% (non-condensing)

Note

Note: Please read description carefully. Do not base your order on the picture presented.
