Owon, HSA015-TG, HSA1000 Series Spectrum Analyzer 1.5GHz, traking generator

Features:

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Frequency Range	9kHz - 1.5 GHz
Frequency Resolution	1Hz
Aging rate	<1ppm/Year
Phase Noise (fc=1GHz)	<-80 dBc/Hz at10 kHz offset
Resolution Bandwidth (-3dB) (RBW)	10 Hz to 500 kHz (1-10 steps by sequence), 1 MHz, 3 MHz
Video Bandwidth(-3dB)(VBW)	10Hz to 3MHz
Detectors	Positive-peak, negative-peak, sample, normal, RMS
Trace functions	Clear write, Max Hold, Min Hold, View, Blank, Average
Level unit	dBm,dBuW,dBpW,dBmV,dBuV, W,V
Tracking generator (-TG Model)	100 kHz-1.5 GHz
Output power level range (-TG Model)	-30 dBm-0 dBm
Output power level resolution (-TG Model)	1dB
Communication Port	USB HOST, USB DEVICE, LAN, earphone port
Display	8 inch touch LCD

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Frequency Range	9kHz - 1.5 GHz
Frequency Resolution	1Hz
Aging rate	<1ppm/Year
Phase Noise (fc=1GHz)	<-80 dBc/Hz at10 kHz offset
Resolution Bandwidth (-3dB) (RBW)	10 Hz to 500 kHz (1-10 steps by sequence), 1 MHz, 3 MHz
Video Bandwidth(-3dB)(VBW)	10Hz to 3MHz
Detectors	Positive-peak, negative-peak, sample, normal, RMS
Trace functions	Clear write, Max Hold, Min Hold, View, Blank, Average
Level unit	dBm,dBuW,dBpW,dBmV,dBuV, W,V
Tracking generator (-TG Model)	100 kHz-1.5 GHz
Output power level range (-TG Model)	-30 dBm-0 dBm
Output power level resolution (-TG Model)	1dB
Communication Port	USB HOST, USB DEVICE, LAN, earphone port
Display	8 inch touch LCD
