| Electrical Data |
| Frequency AC [Hz] | 47 - 64 |
| Operating Voltage Tolerance [%] | 10 |
| Operating Voltage Tolerance 2 [%] | 10 |
| Operating Voltage [V] | Automatic range selection |
| Nominal Voltage AC [V] | <230 |
| Nominal frequency AC [Hz] | 50 - 60 |
| Input Voltage Range AC [V] | 100 - 120 / 200 - 240 |
| Output Voltage DC [V] | 24 - 28 |
| Protection Class | I; (IEC 61140) |
| Overvoltage protection | Yes; (<39 DC) |
| Output Voltage [V] | Adjustable; Output Voltage to SELV, PELV |
| Maximum Output Current at Minimum Output Voltage [A] | 10 |
| Maximum Output Current at Maximum Output Voltage [A] | 8.6 |
| Maximum Output Current Peak at Minimum Output Voltage [A] | 12 |
| Maximum Output Current Peak at Maximum Output Voltage [A] | 10.3 |
| Output Power (Permanent) [W] | 240 |
| Output Power (Peak) [W] | 288 |
| Power Factor (Nominal Voltage 120 V AC / 60 Hz) | 0.59 |
| Power Factor (Nominal Voltage 230 V AC / 50 Hz) | 0.51 |
| Power Reserve [%] | 20 |
| Number of Output Circuits | 1 |
| Maximum Residual Ripple [mV] | 50 |
| Switch-on Peak Current (Nominal Voltage 120 V AC / 60 Hz) [A] | 3 |
| Switch-on Peak Current (Nominal Voltage 230 V AC / 50 Hz) [A] | 3 |
| Inrush Current limitation | Yes |
| Efficiency (Nominal Voltage 120 V AC / 60 Hz) [%] | 91 |
| Efficiency (Nominal Voltage 230 V AC / 50 Hz) [%] | 91.6 |
| External Input Protection | ≤ B-10 A / ≤ C-6 A |
| Derating [W/K] | 6 (60 - 70 °C) |
| Mains Buffering Time (Nominal Voltage 120 V AC / 60 Hz) [ms] | 46 |
| Mains Buffering Time (Nominal Voltage 230 V AC / 50 Hz) [ms] | 47 |
| Input Current (Nominal Voltage 120 V AC / 60 Hz) [A] | 3.73 |
| Input Current (Nominal Voltage 230 V AC / 50 Hz) [A] | 2.23 |
| Power Loss (Nominal Voltage 120 V AC / 60 Hz) [W] | 23.7 |
| Power Loss (Nominal Voltage 230 V AC / 50 Hz) [W] | 22 |
| Back Feeding Protection [V] | 35 |
| Outputs |
| Short-Circuit Proof | Yes |
| Overload Protection | Yes |
| Overload Performance | Constant output current |
| Type DC-OK signal | Relay output |
| Reliability of the DC OK signal | 60 V DC (0.3 A) / 30 V DC (1 A) / 30 V AC (0.5 A) |
| Operating Conditions |
| Ambient Temperature [°C] | -25 - 70 |
| Storage Temperature [°C] | -40 - 85 |
| Maximum Relative Air Humidity [%] | 95; (IEC 60068-2-30) |
| Protection | IP 20; (EN 60529) |
| Degree of Soiling | 2; (IEC 62103: conductive soiling not permitted) |
| Overheat protection | Yes |
| Mechanical Data |
| Weight [g] | 875.5 |
| Type of Mounting | Rail; (TH35 (EN 60715)) |
| Dimensions [mm] | 124 x 62 x 122.5 |
| Material | Steel sheet |
