Buy CTI GG-O2-C0-ST, Gas Sensor O2, 0-25% ppm, SS

info@PrimeBuy.com

1-855-969-9322
1-908-282-3332 (Intl.)

Options and Related Products

Enclosure Type:: Enclosure Type: Stainless Steel
ppm:: ppm: 0-25%

Calibration Technologies (CTI), GG-O2-C0-ST, Gas Sensor, Oxygen (O2), 0-25% Electrochemical, Stainless Steel Enclosure

Features:

Oxygen monitor for ranges 0-25% and 15-25%.
Designed "food industry tough" for wash-down areas, blast cells, engine rooms, etc.
Circuit board sealed in potting material to protect sensitive sensor components and copper tracing from corrosion.
Environmentally adaptive, NEMA 3RX heated Enclosures safe for outdoors and washdown areas.
Built in 3 stage heater for freezing temperatures.
SGS listed to UL 61010-1, and CSA C22.2 No. 61010-1-12

See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

Enclosure

Polycarbonate: Injection-molded, NEMA 3RX washdown duty, with hunged lid and captive screw
Stainless Steel: 18 GA, NEMA 3RX washdown duty, with hinged lid and captive screw

Dimensions

7.7" H x 6.7" W x 3.8" D

Wiring Connection

3-conductor, shielded, stranded, ≥ 20 AWG cable (Belden 8772 or equivalent) up to 1500 ft

Terminal Block Plug (Field Wiring)

26-12 AWG, torque 4.5 lbs-in

Output Signal

4-20 mA linear output

Input Power

+24 vdc

Detection Method

Diffusion

Sensor Technology

Electrochemical

Response Time

T50: < 30 seconds | T90: < 60 seconds

Accuracy

+/- 2%

Zero Drift / month

< 0.5% full scale

Span Drift / month

< 1% full scale

Linearity

+/- 0.5%

Repeatability

+/- 1% full scale

Operating Temperature

-50°F to +122°F

Operating Humidity

5-100% condensing

Certification

SGS listed to UL 61010-1, and CSA C22.2 No. 61010-1-12

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Product Details

Enclosure

Polycarbonate: Injection-molded, NEMA 3RX washdown duty, with hunged lid and captive screw
Stainless Steel: 18 GA, NEMA 3RX washdown duty, with hinged lid and captive screw

Dimensions

7.7" H x 6.7" W x 3.8" D

Wiring Connection

3-conductor, shielded, stranded, ≥ 20 AWG cable (Belden 8772 or equivalent) up to 1500 ft

Terminal Block Plug (Field Wiring)

26-12 AWG, torque 4.5 lbs-in

Output Signal

4-20 mA linear output

Input Power

+24 vdc

Detection Method

Diffusion

Sensor Technology

Electrochemical

Response Time

T50: < 30 seconds | T90: < 60 seconds

Accuracy

+/- 2%

Zero Drift / month

< 0.5% full scale

Span Drift / month

< 1% full scale

Linearity

+/- 0.5%

Repeatability

+/- 1% full scale

Operating Temperature

-50°F to +122°F

Operating Humidity

5-100% condensing

Certification

SGS listed to UL 61010-1, and CSA C22.2 No. 61010-1-12

Note

Note: Please read description carefully. Do not base your order on the picture presented.
