| Camera |
| Image sensor | 1/1.8" progressive scan RGB CMOS |
| Lens | - Varifocal, 4.3-8.6 mm, F1.5
- Horizontal field of view: 100°-53°
- Vertical field of view: 54°-30°
- Remote zoom and focus, P-Iris control, IR corrected
|
| Day and night | Automatically removable infrared-cut filter |
| Minimum illumination | - With Forensic WDR and Lightfinder 2.0:
- Color: 0.14 lux at 50 IRE, F1.5
- B/W: 0 lux at 50 IRE, F1.5
|
| Shutter speed | 1/8500 s to 1/5 s |
| Camera adjustment | Pan ±180°, tilt ±75°, rotation ±175° |
| System on chip (SoC) |
| Model | ARTPEC-7 |
| Memory | 2048 MB RAM, 512 MB Flash |
| Compute capabilities | Machine learning processing unit (MLPU) |
| Video |
| Video compression | - H.264 (MPEG-4 Part 10/AVC) Baseline, Main and High Profiles
- H.265 (MPEG-H Part 2/HEVC) Main Profile
- Motion JPEG
|
| Resolution | 3840x2160 to 160x90 |
| Frame rate | 25/30 fps with power line frequency 50/60 Hz |
| Video streaming | - Multiple, individually configurable streams in H.264, H.265, and Motion JPEG
- Axis Zipstream technology for H.264 and H.265
- Controllable frame rate and bandwidth
- VBR/ABR/MBR H.264/H.265
- Low latency mode
|
| Multi-view streaming | Up to 2 individually cropped out view areas in full frame rate |
| Image settings | Compression, color saturation, brightness, sharpness, contrast, local contrast, white balance, day/night threshold, tone mapping, exposure control (including automatic gain control), motion-adaptive exposure, exposure zones, defogging, Forensic WDR: up to 120 dB depending on scene, barrel distortion correction, fine tuning of low-light behavior, dynamic text and image overlay, privacy masks, mirroring, rotation: 0°, 90°, 180°, 270°, including Corridor Format |
| Pan/Tilt/Zoom | Digital PTZ, preset positions |
| Audio |
| Audio features | - Automatic gain control
- Voice enhancer
|
| Audio streaming | Configurable duplex: Two-way (half duplex, full duplex) |
| Audio input/output | Two-way audio connectivity through optional AXIS T61 Audio and I/O Interfaces with portcast technology |
| Audio input | - Input for external unbalanced microphone, optional 5 V microphone power
- Digital input, optional 12 V ring power
- Unbalanced line input
|
| Audio output | Line output |
| Audio encoding | 24bit LPCM, AAC-LC 8/16/32/44.1/48 kHz, G.711 PCM 8 kHz, G.726 ADPCM 8 kHz, Opus 8/16/48 kHz Configurable bit rate |
| IR illumination | OptimizedIR with power-efficient, long-life 850 nm IR LEDs |
| Operating conditions | - -40 °C to 50 °C (-40 °F to 122 °F)
- Maximum temperature (intermittent): 55 °C (131 °F)
- Absolute maximum temperature: 74 °C (165 °F) according to
- NEMA TS2 2016, 2.2.7
- Start-up temperature: -30 °C to 50 °C (-22 °F to 122 °F)
- Humidity 10-100% RH (condensing
|
| Storage conditions | -40 °C to 65 °C (-40 °F to 149 °F) Humidity 5-95% RH (non-condensing) |
| Dimensions | Without weathershield: Height: 104 mm (4.09 in) ø 149 mm (5.87 in) |
| Weight | With weathershield: 800 g (1.8 lb) |
