| IP video input | 64 channels |
| Network bandwidth | - Downstream: 640Mbps
- Upstream: 640Mbps
|
| Resolution | - 16MP
- 12MP
- 8MP
- 6MP
- 5MP
- 4MP
- 3MP
- 1080P
- 1280x1024
- 960P
- 720P
- 960H
- D1
- CIF
|
| Output | - HDMI1: 7680×4320@60, 7680×4320@30, 3840×2160@60, 3840×2160@30, 1920×1080, 1280×1024, 1024×768 (HDMI2 unavailable if HDMI1 is 8K)
- HDMI2: 3840×2160@60, 3840×2160@30, 1920×1080, 1280×1024, 1024×768
- HDMI3: 3840×2160@60, 3840×2160@30, 1920×1080, 1280×1024, 1024×768
- HDMI4: 1920×1080, 1280×1024, 1024×768
- VGA×1: 1920×1080, 1280×1024, 1024×768 (VGA and HDMI1 output the same video source)
|
| Multi-screen display mode | - Main output: 1/4/6/8/9/13/16/25/32/36/64
- AUX output1: 1/4/6/8/9/13/16/25/32/36
- AUX output2: 1/4/6/8/9/13/16
- AUX output3: 1/4/6/8/9/13/16
- Max: 132 (64+36+16+16)
|
| Compression | |
| Audio |
| Network input | 64 channel IPC audio input |
| Local input | RCA×1 (for 2-way audio) |
| Local output | RCA×1 |
| HDMI audio output | Support |
| Compression | G.711 (U/A) |
| Record |
| Resolution | - 16MP
- 12MP
- 8MP
- 6MP
- 5MP
- 4MP
- 3MP
- 1080P
- 1280x1024
- 960P
- 720P
- 960H
- D1
- CIF
|
| Frame rate | NTSC: 30fps, PAL: 25fps |
| Playback |
| Simultaneous playback | Max 16 channels |
| Search | - Time slice
- Time
- Event
- Tag
- Smart search
|
| Function | Play, Pause, Fast forward, Rewind, Digital Zoom, Previous Frame, Next Frame, etc. |
| Decoding capability |
| Live view | 1 channel 16MP@30 / 4 CH 12MP (only available for main output) |
| Playback | 1 channel 16MP@30 / 4CH 8MP (only available for main output) |
| Alarm |
| Mode | Manual, Sensor, Motion, Exception, Smart Event, etc. |
| Input | 16 channels |
| Output | 4 channels |
| Triggering | Record, Snapshot, Preset, e-Mail, etc. |
| Face |
| Face detection (AI by IPC) | 64 channels |
| Face detection (AI by device) | 4 channels |
| Face match performance | 16 channels |
| Comparison capability | 36 pictures/second |
| Face picture database | 32 libraries, 10000 face pictures |
| Face picture search | Search by picture is supported |
| Database management | Add, Modify, Delete and Search Face Pictures |
| Face picture adding | Add face pictures through APP, WEB and external import |
| Face picture comparison | Supports successful face recognition alarm and stranger match alarm |
| Track | Track display on a map |
| Statistical graph of information | Bar graph |
| Statistical mode of information | Statistics by day, week, month, quarter as well as customized time period |
| Video structure analysis |
| Human/vehicle classification (AI by IPC) | 64 channels |
| Human/vehicle classification (AI by device) | 8 channels |
| Human/vehicle attribute analysis | Yes |
| Other functions |
| Fisheye | Supports fisheye dewarping via NVR/Web Client/mobile APP |
| Plate recognition (AI by IPC) | Yes |
| Network |
| Protocol | - TCP/IP
- HTTP
- HTTPS
- 802.1x
- FTP
- DHCP
- DDNS
- RTP
- RTSP
- RTCP
- NTP
- UPnP
- SMTP
- IPv6
- UDP
- WebSocket
- PPPoE
- SNMP
- IGMP
|
| Interface | RJ45 10/100/1000Mbps ×2 |
| Client connection | Max. 128 users access |
| Mobile device OS | iOS, Android |
| Storage |
| HDD interface | SATA x 8pcs, up to 10TB each |
| RAID type | RAID 0, 1, 5, 6, 10 |
| E-SATA interface | 2 |
| Port |
| USB | USB3.0×1, USB2.0 ×2 (Front:1) |
| RS485 | Yes (full-duplex), connect to PTZ or keyboard |
| Remote controller | Optional |
| Others |
| Power | ATX-200W |
| Consumption | ≤50W (without HDD) |
| Dimensions | 17.51 x 17.16 x 3.54in (445 × 436 × 90mm) (W×D×H) |
| Certificate | CE, FCC |
| Environmental protection | Directive EU RoHS, WEEE(2012/19/EU), Directive 94/62/EC and REACH(EC1907/2006) |
| Working environment | 14°F~122°F (-10°C~50°C); Humidity: 10%~90% |
| HDD Capacity | 30 TB |
