| General |
| Imaging Device | 1/1.8" Progressive CMOS |
| Resolution | - Main Stream: 8MP (3840x2160), 5MP (2592x1944, 3072x1728), 4MP (2592x1520), 3MP (2304x1296), 1080P (1920x1080)
- Sub Stream: 1080P (1920x1080), 720P (1280x720), VGA (640x480)
- Mobile Stream: VGA (640x480), QVGA (320x240)
|
| Min. Illumination | Color: 0.0005lux @ F1.0 (AGC ON); B/W: 0 lux @ IR ON |
| Lens |
| Focal Length (Zoom Ratio) | 3-10mm Motorized |
| Max. Aperture Ratio | F1.0 |
| Angular Field of View | - Horizontal: 105° (W) - 56° (T)
- Vertical: 54° (W) - 32° (T)
- Diagonal: 131° (W) - 65° (T)
|
| Min. Object Distance | W/T 9.8ft (3m) |
| Focus Control | N/A |
| Lens Type | Non-standard interface |
| Operational |
| IR LED | N/A |
| Warm Light | 2 |
| Day & Night | Full Color Mode |
| Backlight Compensation | Off/On (8 Level) |
| Wide Dynamic Range | WDR |
| Digital Noise Reduction | 3D DNR |
| IR Viewable Length | N/A |
| Warm Light Viewable Length | Up to 91ft (25m) |
| Motion Detection | Off/On (8 Level) |
| Privacy Masking | Off/On (4 Zones, Rectangle) |
| Gain Control | AUTO |
| Type of Light | Default warm light |
| Red Blue Light | 2 (1 Red & 1 Blue) |
| Electronic Shutter Speed | AUTO / Manual (1/5 ~ 1/20000s) |
| Analytics | - Face Detection (FD)
- Pedestrian & Vehicle Detection (PD&VD)
- Intrusion Detection (ID)
- Line Crossing Detection (TD)
- Tripwire Counting (TC)
- Stationary Object Detection (OBJ)
- Heat Map (HM)
- Crowd Density Detection (CD)
- Queue Length Detection (QD)
- License Plate Detection (LPR)
- Rare Sound Detection (RSD)
|
| Network |
| Alarm I/O | 1 input, 1 output |
| Hardware Reset | YES |
| Audio In | Built-in MIC |
| Audio Out | Built-in Speaker |
| Ethernet | RJ45 (10/100BASE-T) |
| Video Compression | H.265 / H.264 / H.265+ / H.264+ / MJPEG |
| Audio Compression | G.711a / G.711u |
| Bitrate Control | CBR or VBR (256Kbps ~ 16Mbps) |
| Streaming | Unicast / Multicast |
| Protocol | - TCP/IP
- HTTP
- DHCP
- DNS
- DDNS
- RTP/RTSP
- SMTP
- NTP
- UPnP
- SNMP
- HTTPS
- FTP
- RTMP (v8.2.3 firmware and above)
|
| Security | IP address filter; complicated password; authenticated username and password |
| Application Programming Interface | ONVIF Profile S/G/T |
| Web Viewer | IE10/11, Safari V12.1+, Firefox V52+, Chrome V57+, Edge V79+ |
| General (Additional) |
| Webpage Language | English, Korean |
| Edge Storage | Micro SD/SDHC/SDXC Slot (up to 512GB) with video and still image capture function |
| Environmental & Electrical |
| Operating Temperature / Humidity | -31°F ~ 140°F (-35~+60°C) / ≤ 90% RH |
| Storage Temperature / Humidity | -22°F ~ 140°F (-30~+60°C) / ≤ 95% RH |
| Certification | IP67 / NDAA |
| Input Voltage | DC12V / PoE (IEEE802.3af) |
| Power Consumption | TBD |
| Mechanical |
| Color / Material | White / Metal |
| Product Dimensions | Ø3.45x3.56x11.9in (Ø87.6x90.53x302.18mm) |
