ATC Diversified CMD-120-ASE-1 0.2 to 1 Amp 120V Monitor/Relay

ATC Diversified, CMD-120-ASE-1, Universal 0.2 to 1 Amp AC Current 120V Monitor/Relay

Features:

• The CMD Series may be used as an Over Current Monitor or an Under CURRENT Monitor.
• The CMD has adjustable Delay-on-Operate and adjustable Delay-on-Release time delays.
• When the current exceeds the preset current trip point for longer than the Delay-on-Operate time delay, the internal relay will energize (Pick-up).
• When the current drops below the preset current trip point for longer than the Delay-on-Release time delay, the internal relay will de-energize (dropout).
• When used as an over-current monitor the Delay-on-Operate time delay is used to override inrush periods.
• When used as an Under-current monitor, the Delay-on-Release timer is used to override a temporary Under-current condition.
• An External CT may be used to extend the range of the Current Monitor.

For more information, please see Data Sheet
