Ashly Audio, NE8250.70PE, Network Enabled 8-Channel Amplifier with 4x4 Protea DSP for 70V Systems
Features:
- 10/100 Ethernet comes standard
- DC voltage remote gain control
- Ethernet remote control and monitoring
- Switch mode supply, Class-D output
- Stepped, calibrated input attenuators
- Remote turn on/off
- Disable all front panel controls via software
- Temperature-sensitive variable speed fan with side-to-front airflow
- 4-stage level meters
- Output current and temp indicators
- Safety/Compliance: TUV, CE, FCC, RoHS
The eight-channel power amplifier shall deliver a minimum power of 250 Watts RMS per channel into 70V loads with all channels operating. When switched into bridged-mono mode, channels 1+2 or 3+4 or 5+6 or 7+8 of the amplifier shall deliver at least 500 Watts RMS into a 140V load. The power amplifier shall include Euroblock input connectors and Euroblock output connectors. It shall have balanced analog inputs. The power amplifier shall have remote standby for power up, DC remote level control and contact closure preset recall. It shall have Ethernet control and monitoring of power functions, level, mute, polarity, temperature, current, and amplifier fault conditions. Frequency response shall be 20Hz to 20kHz ±1.0dB. Signal-to-Noise shall be greater than 105dB unweighted and SMPTE intermodulation distortion shall be less than 0.5% into an 8 Ohm load, 10dB below rated output. The front panel shall provide the status of power, standby, protect, power switch disable, signal level, bridge, over-temperature, overcurrent, and Ethernet communication.
For more information, please see
Data Sheet
