Features:

Supports EATX/ATX motherboard in short-depth (19.85 in.) 1U Rackmount chassis for dense computing applications
Support for four hot swap 3.5" SAS/SATA/SSD drive bays
Support 1U single and redundant power supply
Supports 1 full-height/half-length PCI-E x16 Expansion Slot
Easy swap and anti-vibration FAN design
Two front USB ports and one front COM port

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Subject to the use of all the optional accessories

Front I/O Interface

COM Port 1
USB 2.0 10 D-sub openings supporting up to 10 COM

Cooling

4 (4cm / 23 CFM)

Environment

Non-Operating Humidity 10 ~ 95% at 40° C, non-condensing
Non-Operating Vibration (5 ~ 500 Hz) 0.5 Grms
Non-Operational Temperature -40 ~ 70° C (-40 ~ 158° F)
Operating Humidity 10 ~ 85% at 40° C, non-condensing
Operating-Temperature 0 ~ 35° C (32 ~ 95° F)
Vibration (5 ~ 500 Hz) 0.25 Grms

Physical Characteristics

Dimensions (W x H x D) 437 x 43 x 504 mm (17.2" x 1.7" x 19.85")

Miscellaneous

LED Indicators Power, HDD, LAN1, LAN2, System Information

Drive Bay

Hot Swap External 4 (3.5")
Slim Optical Drive External 1

Expansion Slots

PCIE 1 x PCIe x16

Notes

* Free Ground Shipping within the continental U.S. only (excludes Alaska, Hawaii, PO Boxes and APO/FPO addresses).

Product Details

Subject to the use of all the optional accessories

Front I/O Interface

COM Port 1
USB 2.0 10 D-sub openings supporting up to 10 COM

Cooling

4 (4cm / 23 CFM)

Environment

Non-Operating Humidity 10 ~ 95% at 40° C, non-condensing
Non-Operating Vibration (5 ~ 500 Hz) 0.5 Grms
Non-Operational Temperature -40 ~ 70° C (-40 ~ 158° F)
Operating Humidity 10 ~ 85% at 40° C, non-condensing
Operating-Temperature 0 ~ 35° C (32 ~ 95° F)
Vibration (5 ~ 500 Hz) 0.25 Grms

Physical Characteristics

Dimensions (W x H x D) 437 x 43 x 504 mm (17.2" x 1.7" x 19.85")

Miscellaneous

LED Indicators Power, HDD, LAN1, LAN2, System Information

Drive Bay

Hot Swap External 4 (3.5")
Slim Optical Drive External 1

Expansion Slots

PCIE 1 x PCIe x16

Note: Please read description carefully. Do not base your order on the picture presented.
