Buy Opticon L22XWU1-00, L-22X Barcode Scanner, White

info@PrimeBuy.com

1-855-969-9322
1-908-282-3332 (Intl.)

Features:

Sophisticated ergonomic design with an excellent price-to-performance ratio
High speed 2D CMOS imager
Enhanced motion tolerance
Improved scanning of curved, wide and poorly printed barcodes
Durable - survives five foot drop to concrete
IP42 rating against dust and moisture
Trigger modes: manual, auto-trigger and stand detection

Featuring the perfect combination of performance, durability and reliability, the Opticon L-22X is a 2D CMOS imager. The L-22X is built with anti-microbial plastics that are disinfectant ready enabling the device to be sterilized without hindering its performance while keeping users safe from bacteria in a hospital setting. An impressive design ensures a comfortable grip while the proprietary decode engine accurately captures virtually any barcode with first-time, every-time predictability.

See more product information See less

We aim to show you accurate product information. Here you will find what the manufacturers have provided us with. See our disclaimer.

Technical Details

Reviews

CPU

ARM Coretex-A7, 800MHz, 1Gbit flash memory

Visual

3 color LED

Audible

Buzzer, vibrator

Entry Options

1 scan key

USB

Version 2.0, HID/COM

Light Source

Warm white LED

Scan Method

Monochrome CMOS area sensor

Scan Rate

100fps

Trigger Mode

Manual, auto-trigger, stand detection

Reading Pitch Angle

±65°

Reading Skew Angle

±65°

Reading Tilt Angle

360°

Curvature

Radius > 20 mm (12-digit UPC)

Minimum Resolution At Code 39

0.1 mm

Motion Tolerance

UPC 100% at 2.54m/s

Minimum Pcs Value

0.3

Depth Of Field At

Code 39: 5 mil (0.127 mm) 0.233 - 2.244 in (11 - 57 mm)
Code 39: 10 mil (0.254 mm) 0.354 - 6.141 in (9 - 156 mm)
Code 39: 20 mil (0.508 mm) 1.221 - 12.519 in (31 - 318 mm)
Code 128: 7.9 mil (0.2 mm) 0.944 - 4.409 in (24 - 112 mm)
UPC: 13 mil (0.33 mm) 0.354 - 7.667 in (9 - 195 mm)
PDF417: 6.7 mil (0.169 mm) 0.157 - 2.992 in (4 - 76mm)
PDF417: 10 mil (0.254 mm) 0 - 5.118 in (0 - 130 mm)
QR Code: 8.3 mil (0.212 mm) 0.866 - 1.7323 in (22 - 44 mm)
QR Code: 15 mil (0.381 mm) 0 - 6.339 in (0 - 161 mm)
Datamatrix: 6.7 mil (0.169 mm) 0.866 - 1.89 in (22 - 48mm)
Datamatrix: 10 mil (0.254 mm) 0.079 - 3.779 in (2 - 96 mm)

Dimensions (W x H x D)

6.51 x 2.45 x 1.24 in

Weight Body

Ca. 5.4 oz (150 g) (excl. cable)

Case

ABS/PC

Barcode (1D)

UPC-A, UPC-E, UPC-E1, UPC-A Add-on, UPC-E Add-on, EAN-13, EAN-8, EAN-13 Add-on/EAN-8 Add-on, JAN-8, JAN-13, Code 39, Tri-Optic, Codabar, Industrial 2 of 5, Interleaved 2 of 5, S-code, Code 93, Code 128, GS1-128, IATA, MSI/ Plessey, UK/Plessey, Telepen, Code 11, Matrix 2 of 5

Barcode (2D)

PDF417, MicroPDF417, Codablock F, QR Code, Micro QR Code, Data Matrix (ECC 200), DotCode, Maxi Code (Modes 2 to 5), Aztec Code, Chinese Sensible Code, OCR-B

Barcode (Postal Codes)

Chinese Post Matrix 2 of 5, Korean Postal Authority code, Japanese Postal,Intelligent Mail Barcode, POSTNET, PLANET, Netherlands KIX Code, Australian Postal, UK Postal, 4-State Mailmark Barcode

Product Details

CPU

ARM Coretex-A7, 800MHz, 1Gbit flash memory

Visual

3 color LED

Audible

Buzzer, vibrator

Entry Options

1 scan key

USB

Version 2.0, HID/COM

Light Source

Warm white LED

Scan Method

Monochrome CMOS area sensor

Scan Rate

100fps

Trigger Mode

Manual, auto-trigger, stand detection

Reading Pitch Angle

±65°

Reading Skew Angle

±65°

Reading Tilt Angle

360°

Curvature

Radius > 20 mm (12-digit UPC)

Minimum Resolution At Code 39

0.1 mm

Motion Tolerance

UPC 100% at 2.54m/s

Minimum Pcs Value

0.3

Depth Of Field At

Code 39: 5 mil (0.127 mm) 0.233 - 2.244 in (11 - 57 mm)
Code 39: 10 mil (0.254 mm) 0.354 - 6.141 in (9 - 156 mm)
Code 39: 20 mil (0.508 mm) 1.221 - 12.519 in (31 - 318 mm)
Code 128: 7.9 mil (0.2 mm) 0.944 - 4.409 in (24 - 112 mm)
UPC: 13 mil (0.33 mm) 0.354 - 7.667 in (9 - 195 mm)
PDF417: 6.7 mil (0.169 mm) 0.157 - 2.992 in (4 - 76mm)
PDF417: 10 mil (0.254 mm) 0 - 5.118 in (0 - 130 mm)
QR Code: 8.3 mil (0.212 mm) 0.866 - 1.7323 in (22 - 44 mm)
QR Code: 15 mil (0.381 mm) 0 - 6.339 in (0 - 161 mm)
Datamatrix: 6.7 mil (0.169 mm) 0.866 - 1.89 in (22 - 48mm)
Datamatrix: 10 mil (0.254 mm) 0.079 - 3.779 in (2 - 96 mm)

Dimensions (W x H x D)

6.51 x 2.45 x 1.24 in

Weight Body

Ca. 5.4 oz (150 g) (excl. cable)

Case

ABS/PC

Barcode (1D)

Barcode (2D)

PDF417, MicroPDF417, Codablock F, QR Code, Micro QR Code, Data Matrix (ECC 200), DotCode, Maxi Code (Modes 2 to 5), Aztec Code, Chinese Sensible Code, OCR-B

Barcode (Postal Codes)

Chinese Post Matrix 2 of 5, Korean Postal Authority code, Japanese Postal,Intelligent Mail Barcode, POSTNET, PLANET, Netherlands KIX Code, Australian Postal, UK Postal, 4-State Mailmark Barcode

Note

Note: Please read description carefully. Do not base your order on the picture presented.
