Regions | - Australia
- Canada
- European Union
- United Kingdom
- United States
|
Cellular module performance | - 3GPP release 10
- 4G-LTE FDD/TDD category 4
- 150 Mbps peak downlink/50 Mbps peak uplink with 3G/2G fallback
|
Dual SIM | micro (3FF) SIM cards |
Dual Ethernet ports for WAN and LAN connectivity | RJ45 (10/100 BaseT) |
RS 232/RS 485(HD)/DIO | Serial data input and Digital IO; 8-pin terminal connector |
Frequency bands (MHz) | - 4G LTE FDD (Europe): B3 (1800), B7 (2600), B8 (900), B20 (800)
- 2G (Europe fallback): B2 (1900), B3 (1800), B5 (850), B8 (900)
- 4G LTE FDD (AT&T): B2 (1900), B4 (AWS1700), B12 (700), B14 (700)
- 4G LTE FDD (Verizon): B2 (1900), B4 (AWS1700), B13 (700)
- 4G LTE FDD (Anterix): B8-US (900)
- 4G LTE FDD (APAC): B1 (2100), B9 (1800), B18 (800), B19 (850), B26 (850)
- 3G: B1 (2100), B2 (1900), B4 (AWS1700), B5 (850), B6, B8 (900), B19 (850)
- 2G: B2 (1900), B3 (1800), B5 (850), B8 (900)
- 4G LTE FDD bands: B25 (1900)
|
SMS | - Mobile Originate
- Mobile Terminated
- Point-to-Point
|
Wi-Fi, AC00PA models | IEEE 802.11a/b/g/n/ac/ax (2.4 and 5 GHz) |
GNSS, all models | - GNSS systems supported: default
- concurrent GPS/QZSS/SBAS and GLONASS
|
Dimensions | 117 mm x 117 mm x 38 mm (4.61 in. x 4.61 in. x 1.50 in.) |
Weight | 0.5 kg (1 lb) |
Chassis | Aluminum (IP30 rating) |
Mounting options | - Desktop; Wall mount (using Wall-Mount accessory)
- DIN rail mount (using DIN-Mount accessory)
|
Input voltage | 9-36 VDC at 1 A |
Power at 12 VDC | - Idle: 2.4 W (200 mA)
- Maximum: 6.5 W (542 mA)
|
Operating temperature | −40 °C to 75 °C (−40 °F to 167 °F) |
Storage temperature | −40 °C to 85 °C (−40 °F to 185 °F) |
Relative humidity | 15%-93% RH non-condensing |
EMC and radio compliance | CE, FCC, IC, RCM, UKCA |
Safety compliance | - UL/cUL 62368-1 3rd Edition
- IEC 62368-1 3rd Edition including IP30
- AS/NZS 62368.1 3rd Edition
|
Network compliance | PTCRB |
Network operator | AT&T, Verizon |
Quality | - MIL-STD-810G: High Temp, Low Temp, Cold Dwell, Random Vibration, and Sine Vibration
- SAE J1455: Random Vibration and Sine Vibration
|
